Appendix: Master Transportation Plan 2008 Cross-Sections

June 23, 2015Pages 107–1083 sections

Technical drawings of proposed road cross-sections for Admirals Road and Hallowell Road.

1 CALL TO ORDER
Bunt & AssociatesProject No. S441.01February 16, 2007

P105

Shoreline Drive To Admirals Road

Cross-section diagram for Shoreline Drive to Admirals Road showing lane widths for Westbound and Eastbound directions.
Cross-section diagram for Shoreline Drive to Admirals Road showing lane widths for Westbound and Eastbound directions.

Westbound

  • Sidewalk: Existing 1.8m
  • Bike Lane: [Width not specified]
  • Travel Lane: 3.3m
  • Travel Lane: 3.5m

Center

  • Median / TWLT Lane: 3.5m

Eastbound

  • Travel Lane: 3.5m
  • Travel Lane: 3.3m
  • Bike Lane: 1.8m
  • Sidewalk: 3.3m
  • Existing
Page 107–108

ADMIRALS ROAD

Island Highway To Glentana Road

Southbound

  • Sidewalk: Existing 1.5m
  • Bike Lane: [Width not specified]
  • Travel Lane: 3.3m
  • Travel Lane: 3.5m

Center

  • Turn Lane: 3.5m

Northbound

  • Travel Lane: 3.5m
  • Travel Lane: 3.3m
  • Bike Lane: 1.5m
  • Sidewalk: 2.0m
REV DATE BY DESCRIPTION
Project Information Details
TITLE PROPOSED ISLAND HIGHWAY CROSS SECTIONS THETIS OVERPASS TO HELMCKEN ROAD VIEW ROYAL, BC
DRAWN BY wwg
DATE FEB 16 2007
DWG NAME 5441.01-X1
PROJECT No. 5441.01
APPROVED BY
DATE
DRAWING NO 5441.01-Xa
SCALE (DWG) 1:250
SCALE (PLOT) 1:1
REV 0
Page 107–108

P106

Glentanna Road To Hallowell Road

Cross-section diagram for Glentanna Road to Hallowell Road showing lane widths for Southbound and Northbound directions.
Cross-section diagram for Glentanna Road to Hallowell Road showing lane widths for Southbound and Northbound directions.

Southbound

  • Sidewalk: Existing 1.5m
  • Bike Lane: [Width not specified]
  • Travel Lane: 3.3m
  • Travel Lane: 3.5m

Center

  • Turn Lane: 3.5m

Northbound

  • Travel Lane: 3.5m
  • Bike Lane: 1.5m
  • Sidewalk: 2.0m

Hallowell Road

Westbound

  • Sidewalk: 2.0m
  • Bike Lane: 1.5m
  • Travel Lane: 3.3m

Center

  • Median / Turn Lane: 3.5m

Eastbound

  • Travel Lane: 3.3m
  • Bike Lane: 2.0m
  • Boulevard: 1.5m
  • Sidewalk: 2.0m
REV DATE BY DESCRIPTION
Project Information Details
TITLE PROPOSED ISLAND HIGHWAY CROSS SECTIONS THETIS OVERPASS TO HELMCKEN ROAD VIEW ROYAL, BC
DRAWN BY wwg
DATE FEB 16 2007
DWG NAME 5441.01-X1
PROJECT No. 5441.01
APPROVED BY
DATE
DRAWING NO 5441.01-Xa
SCALE (DWG) 1:250
SCALE (PLOT) 1:1
REV 0
Page 107–108
