Council Meeting/Documents/Appendix 5: Plan of proposed construction (plan view)
Appendix

Appendix 5: Plan of proposed construction (plan view)

May 1, 2012Page 221 section

Technical drawings showing the plan view of the proposed upper and lower deck extensions.

Project: Proposed Deck ExtensionArchitectural firm: Mesa Design Group
Technical architectural drawings for the residence at 2329 Evelyn Heights, featuring a deck framing plan, an upper deck extension elevation, and a lower deck plan.
Technical architectural drawings for the residence at 2329 Evelyn Heights, featuring a deck framing plan, an upper deck extension elevation, and a lower deck plan.

Technical Drawing Details: 2329 Evelyn Heights

Proposed Deck Framing Plan (Scale 1:50)

  • Structural Notes:
    • 10" x 10" concrete pier on 12" x 12" concrete footing, 4'-0" below grade.
    • Existing post and beam to remain.
    • 2-2" x 10" beam.
    • Structural slapping foundation.

Proposed Upper Deck Extension (Scale 1:50)

  • Elevation Details:
    • Proposed deck area.
    • Re-install existing deck components.
    • Existing posts to remain.
    • Remove bottom railing and install new stairs per engineer's details.
    • Family room location indicated below the upper deck.

Proposed Lower Deck (Scale 1:50)

  • Plan Details:
    • Line of proposed new deck.
    • Line of existing deck to be extended and/or removed under deck.
    • Re-install existing stairs and railings to align with the new deck.
    • View railings.
    • 60" height privacy deck.

Project Information

  • Client: Mr. Chris Barker
  • Design Consultant: Mesa Design Group, 803 - 440 Viewroyal Ave. Victoria, BC
  • Drawing No: 9774
  • Scale: As Shown
  • Designed By: D.L.
  • Drawn By: D.L.
Page 22
