Appendix 6: Plan of proposed construction (elevation view)

May 1, 2012Page 232 sections

Architectural elevation drawings showing the profile and height of the proposed new deck structure.

Project: 2329 Evelyn Heights Deck Extension
Architectural elevation drawings for the proposed rear deck at 2329 Evelyn Heights, showing rear and side views with annotations for existing deck lines, glass railings, and stone veneer.
Architectural elevation drawings for the proposed rear deck at 2329 Evelyn Heights, showing rear and side views with annotations for existing deck lines, glass railings, and stone veneer.
Page 23

Plan of Proposed Construction (Elevation View)

Project Details

  • Project: Proposed Rear Deck Elevation
  • Client: Mr. Chris Barker
  • Location: 2329 Evelyn Heights, Victoria, BC
  • Design Firm: Mesa Design Group, 609-649 Viewfield Ave, Victoria, BC
  • Date: Feb. 16, 2012
  • Drawing No: 9774

Elevation Annotations

  • Line of existing deck
  • Engineered glass railing
  • Stone veneer
Page 23
Extracted from: 2012 05 01 Council Agenda
