Appendix

Compound Layout Plan - Drawing B19-3027-102.1

May 15, 2012Page 871 section

Close-up plan of the fenced compound including the backup generator and propane storage.

1. CALL TO ORDER

1:75 scale

COMPOUND LAYOUT PLAN

Engineering drawing titled "COMPOUND LAYOUT PLAN" showing the site layout for a telecommunications facility. The plan includes a 55m self-support tower, an equipment shelter, a DC generator and propane storage area, and a fenced compound with dimensions and survey points.

Site Plan Details

DC GENERATOR AND PROPANE STORAGE OPTION 1. SEE TRK ENGINEERING DRAWINGS
W/G BRIDGE AND FOUNDATION BY WESTOWER
55m SELF-SUPPORT TOWER AND FOUNDATION BY WESTOWER
2135mm HIGH CHAIN LINK FENCE c/w MANGATE ACCESS GATE TO TELUS STANDARDS
TELUS EQUIPMENT SHELTER 810 (2590 x 3208 o/o) (8'-6" x 10'-6")
915mm MANGATE
STAIRS TO SUIT GROUND
COMPOUND LAYOUT PLAN (Scale 1:75)

Plan Dimensions and Points

Perimeter/Fencing Dimensions (mm): 7100, 600, 1700, 6200, 3241, 2130, 2438, 500, 3188
Internal Layout Dimensions (mm): 2283, 630, 2641
Survey/Reference Points: 264, 263, 265, 180, 178, 94

Revision History

REVISIONS	DATE	NO.
CLIENT REVIEW/COMMENT	OCT. 26, 2011	1
ISSUED FOR CONSTRUCTION	APR. 20, 2012	2
TOWER HEIGHT REVISED	MAY 4, 2012	3

Project Information

ROBERTSON KOLBEINS TEEVAN GALLAHER ASSOCIATES LTD CONSULTING ENGINEERS 1065 W. 4TH AVE. VANCOUVER, BRITISH COLUMBIA V6J 1M8

RKTG BC0553 — MUNNS ROAD

DRAWING No.: B19-3027-102.1 REV. 3

COMPOUND LAYOUT PLAN

Field	Name	Date / Scale
ENG:	G. ANDERSEN	DATE: OCT. 2011
DR:	A. PADUA	PLOT: 1 : 1
CHK:	G. ANDERSEN	PLOT DATE: MAY 4, 2012
APP:	R. CARTER

TELUS
