B.C. Land Surveyor's Proposed Subdivision Plan (Attachment 4)
A technical survey plan showing the proposed four-lot subdivision layout and the area of road dedication.
B.C. Land Surveyor’s Proposed Subdivision of:
That Part of Lot F, Section 3, Esquimalt District, Plan 3823 Shown Outlined in Red on Plan 383-R
- Civic address: 244 Fenton Road
- Parcel identifier number: 003-439-884
Charges Against Title:
- right of way 77381G
- statutory right of way EN67389
- statutory right of way EN67390
&
The Northerly Part of Lot E, Section 3, Esquimalt District, Plan 3823, Shown Outlined in Red on Plan Deposited Under DD 85722G
- Civic address: 156 View Royal Avenue
- Parcel identifier number: 006-109-993
Charged Against Title:
- restrictive covenant ED551
Annexed to Title:
- restrictive covenant ED559
- restrictive covenant ED560
- restrictive covenant ED562
- restrictive covenant ED563
- restrictive covenant ED564
- restrictive covenant ED565
- restrictive covenant ED566
- restrictive covenant ED567
- restrictive covenant ED568
- restrictive covenant ED569
- restrictive covenant ED570
- restrictive covenant ED571
- restrictive covenant ED572
- restrictive covenant ED573
- restrictive covenant ED574
- restrictive covenant 79445G
Legend
- Denotes iron survey post found
- Denotes non-standard post found
- Denotes lead survey plug found
- Denotes angle iron found
- Denotes utility pole
- Denotes spot elevation
- Denotes tree and tag number (not all trees located)
Notes:
- Elevations are derived from Town of View Royal Control Monuments (preliminary control listing provided by Chris C. Everett, BCLS, January 2007)
- (Monument 05-25 = 15.849 metres)
- Part Lot F Area = +/- 2090.1 m2
- Nly Part Lot E Area = +/- 3487.2 m2
Surveyor Information: Glen Mitchell Land Surveying Inc. 1030 North Park Street Victoria, B.C. V8T 1C6 tel 250-385-1712 fax 250-385-1713 email glen@mitchellsurvey.ca
Preparation Dates: Originally Prepared July 17, 2009 Amended November 30, 2011
Approval Note: Subject to approval by the District of View Royal, proof of ability to service and exemption of 10% frontage regulation.
Tree Table (Proposed Lot 4)
| TAG NO | DIAMETER | PRZ | SPECIES |
|---|---|---|---|
| 1 | 0.33 | 5.0 | garry oak x2 |
| 2 | 0.73 | 13.0 | arbutus |
| 3 | 0.73 | 11.0 | arbutus |
| 9 | 0.37 | 6.5 | garry oak |
| 10 | 0.58 | 11.0 | fir |
| 11 | 0.25 | 4.5 | garry oak |
| 13 | 0.81 | 14.5 | fir |
| 14 | 0.48 | 8.5 | fir |
| 15 | 0.2 | 3.5 | arbutus |
| 18 | 0.76 | 13.5 | fir |
| 31 | 0.3 | 5.0 | fir |
| 73 | 0.43 | 7.5 | fir |
Tree Table (Proposed Lot 1)
| TAG NO | DIAMETER | PRZ | SPECIES |
|---|---|---|---|
| 4 | 0.25 | 4.5 | garry oak |
| 5 | 0.19 | 3.5 | garry oak |
| 6 | 0.3 | 5.0 | garry oak |
| 7 | 0.37 | 6.5 | garry oak |
| 8 | 0.25 | 4.5 | garry oak |
| 12 | 0.60 | 11.0 | arbutus x2 |
| 16 | 0.19 | 3.5 | garry oak |
| 17 | 0.26 | 4.5 | garry oak x3 |
| 19 | 0.33 | 6.0 | garry oak |
| 20 | 0.48 | 8.5 | garry oak x2 |
| 21 | 0.21 | 3.5 | arbutus |
| 22 | 0.19 | 3.5 | arbutus |
| 23 | 0.11 | 2.0 | garry oak |
| 24 | 0.18 | 3.0 | garry oak |
| 25 | 0.25 | 4.5 | garry oak x3 |
| 34 | 0.21 | 3.5 | arbutus |
| 35 | 0.27 | 5.0 | garry oak |
| 36 | 0.21 | 3.5 | garry oak |
| 40 | 0.27 | 5.0 | garry oak |
| 52 | 0.25 | 4.5 | garry oak x3 |
| 62 | 0.22 | 4.0 | arbutus |
| 71 | 0.25 | 4.5 | garry oak |
| 78 | 0.13 | 2.5 | garry oak |
| 94 | 0.18 | 3.0 | garry oak |
| 3353 | 0.16 | 3.0 | garry oak |
| 3354 | 0.16 | 3.0 | garry oak |
| 3449 | 0.18 | 3.0 | arbutus |
Tree species to be confirmed by arborist. PRZ denotes protected root zone.
