Site Plan - 120 Hallowell Rd

November 6, 2012Page 261 section

Technical site plan for the Reliable Controls headquarters.

1. CALL TO ORDER
October 26, 2012D'Ambrosio Architecture

RELIABLE CONTROLS HEADQUARTERS - Site Plan

Architectural site plan for Reliable Controls Headquarters located at 120 Hallowell Rd., View Royal BC. The plan illustrates the footprint of the existing building, showing a "New Glazed Canopy to Match Existing," an "Existing Steel Trellis," and an "Existing Courtyard." The site is bordered by Hallowell Road and Outlook Place, with 7500 front and rear setbacks indicated. The plan also identifies a "Property Line" and an "Outline of Neighbouring Building."
Architectural site plan for Reliable Controls Headquarters located at 120 Hallowell Rd., View Royal BC. The plan illustrates the footprint of the existing building, showing a "New Glazed Canopy to Match Existing," an "Existing Steel Trellis," and an "Existing Courtyard." The site is bordered by Hallowell Road and Outlook Place, with 7500 front and rear setbacks indicated. The plan also identifies a "Property Line" and an "Outline of Neighbouring Building."

Project Information

Field Value
Project Name RELIABLE CONTROLS HEADQUARTERS
Address 120 HALLOWELL RD., VIEW ROYAL BC
Sheet Title Site Plan
Project No. 1201
Drawing File RC DP A1 Site Plan
Date 26 Oct 2012
Scale 1:150
Drawn By mh/mks/sh/td
Checked By FDA
Sheet No. A1.1

Revision History

Rev No Description Date
1 issued for D.P. 2012.10.26
Page 26
