Appendix
ATTACHMENT 5: Fire Truck and Commercial Vehicle Access Sketches
November 7, 2023Pages 121–1223 sections
Technical sketches illustrating turning radii and access paths for fire department vehicles and commercial trucks on the development site.
October 10, 2023Fire truck access sketch
ATTACHMENT 5
Page 121–122
Page 1: 339 Island Highway, Town of View Royal Fire Truck Access Sketch
Site Map and Access Details
Vehicle Turning Paths
Vehicle Specifications
| LANGFORD | meters |
|---|---|
| Width | 2.59 |
| Track | 2.40 |
| Lock to Lock Time | 6.0 |
| Steering Angle | 40.0 |
| HSU | meters |
|---|---|
| Width | 2.60 |
| Track | 2.40 |
| Lock to Lock Time | 6.0 |
| Steering Angle | 40.0 |
CLEARANCE TO FIRE LANE IS PROVIDED IF LOADING BAY IS OCCUPIED BY A HEAVY SINGLE UNIT (HSU) TRUCK
Drawing Information
- SCALE: 1:500
- DRAWN BY: AVK
- DATE: 2023–10–10
- DRAWING No: 22-149-AT-SK1
Page 121–122
Page 2: 339 Island Highway, Town of View Royal Commercial Vehicle Access Sketch
Site Map and Access Details
Vehicle Specifications
| HSU | meters |
|---|---|
| Width | 2.60 |
| Track | 2.40 |
| Lock to Lock Time | 6.0 |
| Steering Angle | 40.0 |
Drawing Information
- SCALE: 1:500
- DRAWN BY: AVK
- DATE: 2023–10–10
- DRAWING No: 22-149-AT-SK2
Page 121–122
