Council Meeting/Documents/TIA APPENDIX C: TRAFFIC SIGNAL WARRANT RESULTS
Appendix

TIA APPENDIX C: TRAFFIC SIGNAL WARRANT RESULTS

November 7, 2023Pages 289–2903 sections

Evaluation of whether a traffic signal is warranted at the study intersection based on MoTI guidelines.

10.a Rezoning Application 2023-01 - 339, 341 and 345 Island Highway
BC MoTI's Electrical & Traffic Engineering Design Guidelines6 collisions in last 5 years

REZONING 2023-01

331, 341, & 345 Island Highway

Page 289–290

PROJECT INFORMATION: Conceptual Design

Conceptual Rendering of Site Plan

Conceptual rendering of the site plan showing building footprints, entry forecourts, outdoor amenity spaces, and woodland trails.
Conceptual rendering of the site plan showing building footprints, entry forecourts, outdoor amenity spaces, and woodland trails.
Amenity Area
Barbeque Area 106 m²
Children’s Play Area & Playground 105 m²
Courtyard Area Open Space Amenity Area 100 m²
Greenspace 4186 m²
Page 289–290

DISCUSSION:

C-5: Tourist Commercial to RM-3: Mixed Residential

  1. Proposal is compliant with existing zone; use, density, setbacks
  2. Requires a single variance to height of building
Annotated site plan diagram with red arrows indicating locations for Access, Fire Access Area, and Loading Area.
Annotated site plan diagram with red arrows indicating locations for Access, Fire Access Area, and Loading Area.
Page 289–290
