Attachment 3: Building Concept

October 17, 2023Pages 219–2201 section

Detailed building concept sketches for the proposed garage at 25 Chancellor Avenue, including material specifications.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:58 p.m.

June 28, 2023Materials: 3/4" Tongue & Grove Plywood with Vinyl coating6"x6" Corner Posts

25 CHANCELLOR AVE

June 28 '23

Hand-drawn architectural sketches of a proposed garage, including a front elevation, an isometric perspective, and a site plan.

High-contrast version of the hand-drawn architectural sketches on page 1.

Garage Dimensions and Site Plan

Front Elevation:
- Structure Width: 4.26 m
- Structure Height (to peak): 3.66 m
- Door Width: 2.74 m
- Door Height: 2.44 m
- Roof Overhang: 30 cm
- Fascia/Overhang Height: 25.4 cm
Isometric View:
- Structure Length: 9.144 m
- Structure Height: 3.66 m
- Front Door Width: 2.74 m
- Side Door: Indicated on the left elevation
- Note: "2.5 m drop" indicated near the roofline
Site Plan:
- Sketch showing the relative positions of the "HOUSE" and "GARAGE"
- Indicated distance between the house and garage: 10 m

Structural Specifications

Hand-drawn cutaway perspective sketch detailing the construction materials and framing components of the garage.

High-contrast version of the structural specification sketch on page 2.

Roofing: 3/4" Toung & Grove Plywood coated with Vinal coating
Rafters: 2" x 10" spaced every 16"
Header: 6" x 6" Header
Posts: 6" x 6" Corner Posts x 4
Wall Studs: 2" x 6" x 10' every 10'
Sill Plate: 10' 2" x 4"
Siding: "x 8" siding Match House
Top Trim: 1" x 10"

Page 219–220
