Attachment 3: Site Survey of No. 10 Erskine Lane - Drawing A100
A professional site survey plan for 10 Erskine Lane showing existing topography, property lines, and connection to the Galloping Goose Trail.
SITE SURVEY
Project Name: ERSKINE LANE Address: 8 - 10 ERSKINE LANE, COLWOOD BC Drawing Title: SITE SURVEY Drawing No.: A100 Project No.: 2107 Date: DECEMBER 8 2022
Architect: FINLAYSON BONET ARCHITECTURE LTD. #4 - 7855 East Saanich Rd. Saanichton V8M 2B4 Phone: 250-656-2224 Fax: 250-656-2279 Email: info@finlaysonbonet.ca
Revision History
| Rev | Date | Description |
|---|---|---|
| 12/8/2022 | ISSUED FOR DP |
Checked: SMB Drawn: NEA Scale: 1:150
Site Plan Details
BC Land Surveyors Site Plan of No.10 Erskine Lane Legal - Remainder of Lot 3, Plan 4206, Except Part in Plan VIP61887, Section 93, Esquimalt District
Surveyor Information: POWELL & ASSOCIATES BC Land Surveyors 940 View Street Victoria, BC V8V 3L5 Phone: (250) 382-8855 March 7/07 File: 10002site.q (37)
Notes:
- Elevations are based on drain invert (11.34m) provided by the Town of View Royal.
- The plan identifies:
- Rem 3 Plan 4206
- Pt 3 in Plan VIP61887 (area = 342 m²)
- Adjacent Strata Plan VIS3076
- Erskine Lane (including edge of asphalt, service vault (TV), mh, and concrete service pad)
- Galloping Goose Trail
- Topographical contour lines are shown from 8.0m to 15.0m.
Legend
- cb — denotes catch basin
- mh — denotes manhole
- wm — denotes water meter
- up — denotes utility pole
- 25A — denotes 25cm dia. arbutus w/number tag
- 25D — denotes 25cm dia. deciduous w/number tag
- 65F — denotes 65cm dia. fir w/number tag
- 50M — denotes 50cm dia. maple w/number tag
- 55O — denotes 55cm dia. oak w/number tag
