Attachment 4: Site Survey - 10 Erskine Lane

BC Land Surveyors Site Plan of No.10 Erskine Lane

Project Information

• Project Name: ERSKINE LANE
• Address: 8 - 10 ERSKINE LANE, COLWOOD BC
• Drawing Title: SITE SURVEY
• Date: DECEMBER 8 2022
• Drawing No.: A100
• Project No.: 2107
• Architecture Firm: FINLAYSON BONET ARCHITECTURE LTD.
  • Address: #4 - 7855 East Saanich Rd. Saanichton V8M 2B4
  • Phone: 250-656-2224
  • Fax: 250-656-2279
  • Email: info@finlaysonbonet.ca

Revision History

Survey Plan Details

BC Land Surveyors Site Plan of No.10 Erskine Lane

• Legal Description: Remainder of Lot 3, Plan 4206, Except Part in Plan VIP61887, Section 93, Esquimalt District
• Surveyor: POWELL & ASSOCIATES BC Land Surveyors
  • Address: 940 View Street Victoria, BC V8V 3L5
  • Phone: (250) 382-8855
• File: 10002site q (37)
• Original Survey Date: March 7/07

Legend

• cb - denotes catch basin
• mh - denotes manhole
• wm - denotes water meter
• up - denotes utility pole
• 25A - Denotes 25cm dia. arbutus w/number tag
• 25D - Denotes 25cm dia. deciduous w/number tag
• 65F - Denotes 65cm dia. fir w/number tag
• 50M - Denotes 50cm dia. maple w/number tag
• 55F - Denotes 55cm dia. oak w/number tag

Map Notes and Annotations

• Elevations: Elevations are based on drain invert (11.34m) provided by the Town of View Royal.
• Site Features and Boundary Information:
  • Erskine Lane: Shows edge of asphalt, gutter, and service infrastructure (service vault (TV), Telus, concrete service pad).
  • Galloping Goose Trail: Bordering the southern edge of the property.
  • Legal Parcels:
    • Pt 3 in Plan VIP61887 (area = 342.6 m²)
    • Rem 3 Plan 4206
    • Pt A Plan VIP61160
    • Strata Plan VIS3076
  • Topographical Notes:
    • Top of slope and bottom of slope indications.
    • "thick blackberry brushes (unable to obtain elevations)"
    • "corner under water"
    • "sloping terrain with trees"
    • "rocky bluff"
    • Board fence and various gate locations.
