Attachment 4: Site Plan - Drawing A102

ERSKINE LANE - SITE PLAN

Architectural Firm Finlayson Bonet Architecture Ltd. #4 - 7055 East Saanich RD. Saanichton V8M 2B4 Phone: 250-656-2224 Fax: 250-656-2279 Email: info@finlaysonbonet.ca

Project Information

• Project Name: ERSKINE LANE
• Address: 8 - 10 ERSKINE LANE, COLWOOD BC
• Drawing Title: SITE PLAN
• Drawing No: A102
• Project No: 2107
• Date: DECEMBER 8 2022
• Scale: 1:150
• Drawn: NEA
• Checked: SMB

Revision History

Site Plan Details

The site plan illustrates the proposed development at 8 - 10 Erskine Lane, featuring the following details and annotations:

• Site Features and Amenities:

  • Galloping Goose Trail: Located along the southern boundary of the property.
  • BBQ & Sitting Area: Situated in the southwest corner of the site.
  • Gazebo: Located on the western side of the building.
  • GYM / common room: Indicated within the central portion of the building footprint.
  • PMT (Pad Mounted Transformer): Located near the northwest entrance.
  • Exit from parking: Marked at the northern access point.

• Land and Property Information:

  • Pt 3 in Plan VIP61887: Indicated with an area of 342 m².
  • Property Lines: Includes markers for EXISTING Property line, Road dedication Area, and NEW Property line.
  • Setbacks: Various SETBACK lines are noted around the building perimeter.

• Site Dimensions:

  • Western boundary: 65.00
  • Northern boundaries: 25.40 and 31.76
  • Eastern boundaries: 34.23 and 12.00
  • Southern boundaries: 63.89 and 59.44

• Infrastructure and Utilities:

  • The northern edge along the road includes markers for asphalt, gutter, storm, sewer, water, and a sign.
  • Topographic markers and slope directions are indicated throughout the site, including a "Slope down 1.2%" and "Slope down 2%" on the eastern side.
