Attachment 6: Landscape Concept Plan and Viewing Deck Details - 10 Erskine Lane
October 17, 2023Pages 338–3392 sections
Landscape architecture plans and structural details for a viewing deck at the 10 Erskine Lane development site.
Firm: 4 Site Landscape ArchitectureDrawing Number: L100Replacement trees required: 24Dated: July 17, 2023
Landscape Concept Plan: 10 Erskine Lane
[Map: Landscape Concept Plan for 10 Erskine Lane showing building footprint, walkways, and various plantings]
Map Annotations
- PLANTED ISLAND W/ FLOWERING TREE
- UTILITY POLE
- SPECIAL PAVED ENTRYWAY
- BENCH
- TREE IN BOX PLANTER
- BIKE RACK
- FOUNTAIN FEATURE AT ENTRANCE
- CONCRETE WALKWAY TO UNIT
- CONCRETE WALKWAY
- TRELLIS ARBOUR ON CONCRETE RETAINING WALL
- TYPICAL TREATMENT AT UNIT ENTRY:
- SPECIAL PAVED PATIO
- SYNTURF LAWN W/ PLANTED BORDER
- CONCRETE WALKWAY
- TREE & SHRUBS IN BOX PLANTER
- ARBOUR ON RETAINING WALL
- CONIFER HEDGE FOR SCREENING
- HYDROSEEDED BANK
- NEW RAINGARDEN
- OFF-SITE RESTORATION AREA WITH NATIVE PLANTS
- EXISTING STORMWATER POND
- EXISTING VEGETATION
- GARBAGE/RECYCLING AREA
- RETAIN EXISTING TREES
- VIEWING DECK WITH BENCH SEATING
- CONCRETE WALKWAY
- ARBOUR TRELLIS
- CONIFER HEDGE FOR SCREENING
- AMENITY AREA WITH FLOWERING TREE IN BOX PLANTERS, SEATING, PLANTINGS, SINTURF
- HYDRO KIOSK
- RIVER ROCK
- LARGE DECIDUOUS STREET TREE IN PLANTED ISLAND
Suggested Plant List
| Category | Key | Common Name | Latin Name | Size |
|---|---|---|---|---|
| Trees | AMAN | Amanogawa Flowering Cherry | Prunus serrulata var. 'Amanogawa' | 6cm Cal. |
| SASK | Saskatoon Berry | Amelanchier alnifolia var. 'Autumn Brilliance' | 6cm Cal. | |
| KAT | Katsura Tree | Cercidiphyllum japonicum | 7cm Cal. | |
| PDOG | Pacific Dogwood | Cornus nuttallii var. Eddie's White Wonder | 7cm Cal. | |
| GOAK | Garry Oak | Quercus garryana | 6cm Cal. | |
| GLED | Honeylocust | Gleditsia triacanthos | 6cm Cal. | |
| SPIN | Shore Pine | Pinus contorta | 6cm Cal. | |
| LHAW | Lavalle Hawthorn | Crataegus lavallei | 6cm Cal. | |
| Large Shrubs | CEAN | California Lilac | Ceanothus var. 'Victoria' | 1.5m Ht. |
| MAG | Star Magnolia | Magnolia stellata var. 'Royal Star' | #5 Pot | |
| PIER | Lily of the Valley Shrub | Pieris japonica var. 'Forest Flame' & 'Valley Rose' | #5 Pot | |
| LRHB | Rhododendron | Rhododendron var. 'Pink Walloper' | #7 Pot | |
| LRIB | Rhododendron | Rhododendron var. 'Gomer Waterer' | #7 Pot | |
| THUJ | Upright Cedar | Thuja occidentalis var. 'Smaragd' | 1.5m Ht. | |
| HOLO | Oceanspray | Holodiscus discolor | #5 Pot | |
| NINE | Pacific Ninebark | Physocarpus opulifolius | #5 Pot | |
| MAH | Oregon Grape | Mahonia aquifolium | #5 Pot | |
| SALM | Salmonberry | Rubus spectabilis | #5 Pot | |
| Medium Shrubs | ABIE | Glossy Abelia | Abelia x grandiflora | #2 Pot |
| RDOG | Red Twig Dogwood | Cornus stolonifera | #2 Pot | |
| SALA | Salal | Gaultheria shallon | #2 Pot | |
| MAHC | Dwarf Oregon Grape | Mahonia aquifolium var. 'Compacta' | #2 Pot | |
| MRHA | Rhododendron | Rhododendron var. 'Unique' | #2 Pot | |
| MRHB | Rhododendron | Rhododendron var. 'Christmas Cheer' | #2 Pot | |
| RIBE | Red Flowering Currant | Ribes sanguineum var. 'King Edward' | #5 Pot | |
| DVIB | David Viburnum | Viburnum davidii | #2 Pot | |
| ALAT | Dwarf Burning Bush | Euonymus alata var. 'Compacta' | #5 Pot | |
| VACC | Mountain Blueberry | Vaccinium ovatum | #2 Pot | |
| Small Shrubs | AZAW | Evergreen Azalea | Azalea var. 'Gumpo White' | #2 Pot |
| IMEA | Winter Flowering Heather | Erica darleyensis var. 'Arthur Johnson' | #1 Pot | |
| GROS | Bald Hip Rose | Rosa gymnocarpa | #2 Pot | |
| NROS | Nootka Rose | Rosa nutkana | #2 Pot | |
| EUOF | Creeping Euonymus | Euonymus fortunei var. 'Emerald Gaiety' | #1 Pot | |
| MAHN | Cascade mahonia | Mahonia nervosa | #2 Pot | |
| DMMO | Dwarf Mock Orange | Philadelphus lewisii var. 'Snowdwarf' | #2 Pot | |
| DWPJ | Dwarf Lily of the Valley Shrub | Pieris japonica var. 'Debutante' | #2 Pot | |
| POLY | Sword Fern | Polystichum munitum | #1 Pot | |
| SARC | Sweetbox | Sarcococca hookeriana humilis | #1 Pot | |
| SPGF | Goldflame Spirea | Spiraea bumalda var. 'Gold Flame' | #2 Pot | |
| SNOW | Snowberry | Symphoricarpos albus | #2 Pot | |
| AZAN | Azalea x Girard's Pleasant White | Girard's Pleasant White Azalea | #2 Pot | |
| DOGD | Kelsey's Dwarf Dogwood | Cornus sericea var. 'Kelseyi' | #1 Pot | |
| SPIR | Spirea | Spiraea bumalda var. 'Shirobana' | #2 Pot | |
| Ground Covers | BEAR | Bearberry | Arctostaphylos uva-ursi var. 'Vancouver Jade' | SP4 |
| BERG | Heartleaf Bergenia | Bergenia cordifolia var. 'Bressingham Ruby' | SP5 | |
| GAUL | Wintergreen | Gaultheria procumbens | SP4 | |
| AJUG | Bugleweed | Ajuga reptans var. 'Bressingham Ruby' | SP4 | |
| COTO | Creeping Cotoneaster | Cotoneaster dammeri | SP4 | |
| VITI | Lingonberry | Vaccinium vitis-idaea | SP4 | |
| Vines | ARM | Evergreen Clematis | Clematis armandii | #5 Pot |
| WIST | Wisteria | Wisteria sinensis var. 'Black Knight' | #7 Pot | |
| Perennials & Grasses | SCIZ | Kaffir Lily | Schizostylis coccinea var. 'Oregon Sunset' | SP5 |
| HEUC | Coral Bells | Heuchera var. 'Palace Purple' | SP5 | |
| TEST | Flame Sedge | Carex testacea | #1 Pot | |
| CARV | Variegated Sedge | Carex morrowii 'aureo-variegata' | SP5 | |
| JUNC | Common Rush | Juncus effusus | #1 Pot | |
| MISC | Maiden Hair Grass | Miscanthus sinensis | #1 Pot | |
| Wildflowers & Bulbs | CAMA | Common Camas | Camassia quamash | Bulb |
| DODE | Shooting Star | Dodecatheon hendersonii | Bulb | |
| ERYT | Easter Lily | Erythronium oregonum | Bulb | |
| FRIT | Chocolate Lily | Fritillaria lanceolata | Bulb |
Notes:
- All landscape work to conform with B.C.S.L.A. / B.C.N.T.A. standard specification.
- All areas to be irrigated with an automatic underground system.
Project Notes
- REFER TO ARBOURIST REPORT FOR TREE RETENTION/REMOVAL INFORMATION.
- REPLACEMENT TREES REQUIRED: 24
- REPLACEMENT TREES PROVIDED (ON & OFF SITE): 24
Legend
- LARGE AND SMALL CONIFEROUS TREES
- LARGE SHRUB
- MEDIUM SHRUB
- SMALL SHRUB
- GROUND COVER & PERENNIALS
- LARGE DECIDUOUS SHADE TREE
- SMALL ORNAMENTAL DECIDUOUS TREES
- TREES TO BE RETAINED
- TREES TO BE REMOVED
- TREE ROOT ZONE
Document Information
Revisions
| REV. DATE | NUMBER | DESCRIPTION |
|---|---|---|
| 2022-10-14 | 1 | PRELIM. CONCEPT PLAN - FOR REVIEW |
| 2022-10-19 | 2 | PRELIM. CONCEPT PLAN - REVISED |
| 2022-11-09 | 3 | CONCEPT PLAN - REVISED |
| 2023-06-08 | 4 | CONCEPT PLAN - REVISED |
Details
- Date: JULY 17, 2023
- Scale: 1:100
- Drawn By: BF
- Sheet Number: L100
Page 338–339
Viewing Deck (Typ.) Detail
[Diagram: Technical detail for a viewing deck showing structural components and materials]
- Scale: 1/2" = 1' - 0"
Detail Annotations
- 3" X 8" PRESSURE TREATED WOOD CAP RAIL
- 2" X 6" WOOD CAP BASE
- GALVANIZED METAL PIPE FRAME ANCHORED TO POSTS C/W BLACK VINYL COATED CHAIN LINK WIRE RAILING PANELS
- 3'-6" (1065 mm) railing height
- 6" X 6" PRESSURE TREATED TIMBER POSTS - REFER TO DECK PLAN FOR LOCATION - REFER TO STRUCTURAL
- 3" X 8" ROUGH SAWN PRESSURE TREATED WOOD DECKING
- 2" X 10" ROUGH SAWN PRESSURE TREATED WOOD FASCIA
- 2" X 10" (X2) WOOD BEAM - BOLT THRU POSTS (2 PER CONNECTION)
- HEAVY DUTY GALVANIZED STEEL POST SADDLES C/W EXTRA LONG ANCHOR TAILS - 1 PER POST - BOLT THRU POST - 2 PER CONNECTION
- 12" Ø 30 Mpa CONCRETE POST FOOTINGS - REFER TO STRUCTURAL
Page 338–339
