Council Meeting/Documents/297 VIEW ROYAL - Design Imagery
Appendix

297 VIEW ROYAL - Design Imagery

June 6, 2023Page 931 section

Visual examples of the proposed Flex MSE vegetated wall system and gabion retaining walls.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.
Features: Flex MSE vegetated wall, Gabion retaining walls, shoreline restoration

297 VIEW ROYAL

Photo of the Flex MSE vegetated wall system, showing both the structural bags and the final vegetated state
Photo of the Flex MSE vegetated wall system, showing both the structural bags and the final vegetated state
FLEX MSE VEGETATED WALL SYSTEM
Photo of terraced gabion retaining walls planted with ornamental grasses
Photo of terraced gabion retaining walls planted with ornamental grasses
GABION RETAINING WALLS LINED WITH COMPOSTABLE COCONUT FIBRE MAT
Photo of natural shoreline restoration with lush green vegetation along the water's edge
Photo of natural shoreline restoration with lush green vegetation along the water's edge
SHORELINE RESTORATION
Page 93
