Existing and Proposed Site Plan - 1681 Island Highway
Drawing comparisons showing existing and proposed site layout for 1681 Island Highway.
McKay's Home Theatre
1681 Island Highway, View Royal, BC
Project Information
Architects: de Hoog & Kierulf architects Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367 Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 2K8 | T 1 • 250 • 585 • 5810
| Drawing Title | Site Plan |
|---|---|
| Drawing No. | A02 |
| Project Number | 1645 |
| Date | 25 April 2017 |
| Scale | 1:200 (as noted) |
| Drawn By | neb |
| Checked By | pdh |
| Drawing File | 1645 Wilfert Road.vwx |
Revision History
| Rev | Date | Description |
|---|---|---|
| - | 07 MAR 17 | Issued for Development Permit |
NOTE: All dimensions are shown in millimeters.
Site Plan - Existing
Scale: 1:200
This diagram illustrates the existing site layout, bounded by Island Highway and Wilfert Road.
- Buildings: Existing Building centrally located on the lot.
- Loading Area: 32 m² (8475 mm x 3730 mm).
- Parking Area: 67 Stalls, numbered 1 through 67.
Site Plan - Proposed
Scale: 1:200
This diagram illustrates the proposed site modifications, bounded by Island Highway and Wilfert Road.
- Buildings: Existing Building remains; a New Accessory Building is added to the northeast corner.
- New Accessory Building Details: Noted length of 14800 mm and 1200 mm setbacks.
- Loading Area: 32 m² (8475 mm x 3730 mm).
- Parking Area: 61 Stalls, numbered 1 through 61.
