Building Plans and Elevations - 1681 Island Highway

McKay's Home Theatre

Architectural Plans

Project Name: McKay's Home Theatre Address: 1681 Island Highway, View Royal, BC Architect: de Hoog & Kierulf architects Victoria Office: 977 Fort Street, Victoria BC V8V 3K3 | T 1 • 250 • 658 • 3367 Nanaimo Office: 102 - 5190 Dublin Way, Nanaimo BC V9T 2K8 | T 1 • 250 • 585 • 5810

Drawing Title: Plans Drawing No.: A03 Date: 25 April 2017 Project Number: 1645 Drawn by: pdh Checked by: neb Scale: as noted

Revision History

Materials Schedule

---

Drawing Details

NOTE: All dimensions are shown in millimeters.

1 Floor Plan

• Scale: 1:50
• Details:
  • Overall exterior dimensions: 10775 x 7750
  • Interior floor dimensions: 10375 x 7350
  • Features: CONCRETE SLAB ON GRADE WITH TRAFFIC TOPPING
  • Shows layout for three overhead doors and indicates skylight positions (X3) above.

2 Building Cross Section

• Scale: 1:50
• Details:
  • Space identified as: GARAGE (Unconditioned Space)
  • Interior clear height: 4200
  • Overall building height: 4500

3 West Elevation

• Scale: 1:50
• Details:
  • Features three aluminum and polycarbonate panel overhead doors (Material 5).
  • Infill panel callouts: "Translucent polycarbonate infill panels" and "Clear polycarbonate infill panels".
  • Wall material: Material 2 (Cement fibre board panel siding).

4 East Elevation

• Scale: 1:50
• Details:
  • Solid exterior wall using Material 2 siding.
  • Features Material 1 metal flashing at the roofline and Material 3 concrete curb at the base.

5 South Elevation

• Scale: 1:50
• Details:
  • Features one insulated painted metal door with frame and glass transom (Material 4), height 2140.
  • Wall material: Material 2 siding.

6 North Elevation

• Scale: 1:50
• Details:
  • Solid wall construction using Material 2 siding.
