Colours & Materials Presentation - 1681 Island Highway

May 16, 2017Page 321 section

Visual guide to proposed colours, materials, and photos of the existing building at 1681 Island Highway.

8.1.a) Form and Character Development Permit No. 2017/01 - 1681 Island Highway - Mad Man McKay
McKay's Home TheatreMaterials sample photo

McKay's Home Theatre

1681 Island Highway View Royal, BC 25 April 2017

Colours & Materials

West Elevation

[Architectural rendering of the West Elevation featuring three overhead doors and three glass skylights]

South Elevation (partial)

[Architectural rendering of a partial South Elevation showing an insulated painted metal door with a glass transom]

Materials Schedule

  1. PREFINISHED METAL FLASHING (colour to match existing building)
  2. CEMENT FIBRE BOARD PANEL SIDING (colour to match existing building)
  3. CONCRETE CURB
  4. INSULATED PAINTED METAL DOOR/FRAME/GLASS TRANSOM
  5. ALUMINUM AND POLYCARBONATE PANEL OVERHEAD DOOR
  6. PRE-MANUFACTURED GLASS SKYLIGHT (X3)

Overhead Door Example

Close-up photo of an aluminum and polycarbonate panel overhead door with a "MAXIMUM CLEARANCE 2m (6'6")" sign
Close-up photo of an aluminum and polycarbonate panel overhead door with a "MAXIMUM CLEARANCE 2m (6'6")" sign

Materials Samples

Photo of physical material samples including prefinished metal flashing, cement fibre board panel siding, and overhead door panels
Photo of physical material samples including prefinished metal flashing, cement fibre board panel siding, and overhead door panels

Existing Building

Wide perspective photo of the existing building showing a "HUGE SALE TODAY" banner and surrounding parking area
Wide perspective photo of the existing building showing a "HUGE SALE TODAY" banner and surrounding parking area
Close-up photo of the existing building's front entrance and "MCKAY'S" signage
Close-up photo of the existing building's front entrance and "MCKAY'S" signage
Side view photo of the existing building and adjacent parking lot
Side view photo of the existing building and adjacent parking lot
Perspective photo of the building's side elevation with a vehicle parked in the foreground
Perspective photo of the building's side elevation with a vehicle parked in the foreground
Page 32
