Proposed site plan drawing for the nine-unit detached strata residential development at 102 Atkins Road.
102 Atkins RoadDrawing # 7548
102 atkins road AMENDED DEVELOPMENT PERMIT PRESENTATION
Detailed Site Plan for 102 Atkins Road showing the layout of nine proposed detached homes (Lot 1 to Lot 9) situated between a western property boundary and the Galloping Goose regional trail, with road access from Chilco Road.
Project and Site Information
Property: Pcl A (DD L2503) of Lot 6, Section 98, Esquimalt District Plan 748
Project: Proposed Site Plan of 102 ATKINS ROAD
Address: 102 ATKINS ROAD VIEW ROYAL B.C.
Site Area: 6647 m²
Municipality: VIEW ROYAL
Current Zoning: CD-21
PID No: 000-608-131
Drawing Number: 7548
Scale: 1:300
Drawn by: NS
Date: 13/9/17
Site Plan Details
The site plan illustrates a residential development consisting of nine detached homes. The property boundary lengths are noted as 123.69m on the west, 65.65m and 56.48m on the north, and curved eastern boundaries of 121.06m, 37.87m, and 67.78m bordering the Galloping Goose regional trail. Access to the development is via Chilco Road on the east.
Site Information Table
SITE INFORMATION TABLE
PERMITTED CD-21
CD-21
ZONE (EXISTING)
6000 sq.m.
6647.05 sq.m.
SITE AREA (sq.m.)
6000 sq.m.
6647.05 sq.m.
TOTAL FLOOR AREA OF BUILDINGS (sq.m.)
2399.22 sq.m.
FLOOR SPACE RATIO
0.60
0.36
LOT COVERAGE %
40 % (max.)
15.05 %
IMPERMEABLE SURFACE COVERAGE
40 % (max.)
38.66 %
HEIGHT OF BUILDINGS (m)
7.5 m (max.)
6.01 - 9.40 m *
NUMBER OF STOREYS
2
IMPERMEABLE DRIVEWAY COVERAGE
1300.30 sq.m.
IMPERMEABLE SURFACE COVERAGE FOR ALL BUILDINGS
1269.63 sq.m.
Site Setbacks
SITE SETBACKS (m)
PERMITTED CD-21
CD-21
FRONT (EAST)
7.50 m
7.50 m
REAR (WEST)
6.00 m
123.69 m
SIDE (NORTH)
1.50 m
2.50 m
SIDE (SOUTH)
1.50 m
2.50 m
Residential Use Details
RESIDENTIAL USE DETAILS
PERMITTED CD-21
CD-21
TOTAL NUMBER OF DETACHED HOMES
9
9
Proposed Floor Areas (Same for all homes)
PROPOSED FLOOR AREAS
PERMITTED CD-21
CD-21
BASEMENT FLOOR
73.12 sq.m.
MAIN FLOOR
74.38 sq.m.
UPPER FLOOR
93.72 sq.m.
GARAGE
25.36 sq.m.
BUILDING FLOOR SPACE (EXCLUDING GARAGE)
max. 325 sq.m.
241.22 sq.m.
TOTAL FLOOR AREA WITH GARAGE (FOR F.S.R.)
266.58 sq.m.
* Variances Required for Building Height For:
LOT 1 FROM 7.5m TO 8.97m
LOT 2 FROM 7.5m TO 9.40m
LOT 3 FROM 7.5m TO 8.93m
LOT 4 FROM 7.5m TO 8.27m
Page 18
