Council Meeting/Documents/Attachment 11 - TYPICAL TYPE C ELEVATIONS
Appendix

Attachment 11 - TYPICAL TYPE C ELEVATIONS

October 17, 2017Page 261 section

Detailed technical architectural elevation views (Front, Rear, Right, Left) for the Type C houses.

Scale: 1/4" = 1'-0"

TYPICAL TYPE C ELEVATIONS

Architectural drawing titled "Typical Type C Elevations" for a development at 102 Atkins Road. The sheet includes four elevation views: Front Elevation (1), Right Side Elevation (2), Rear Elevation (3), and Left Side Elevation (4). Each view is detailed with material callouts such as laminated asphalt shingles, concrete fibre lap siding, pre-manufactured stone veneer, and aluminum gutters.
Architectural drawing titled "Typical Type C Elevations" for a development at 102 Atkins Road. The sheet includes four elevation views: Front Elevation (1), Right Side Elevation (2), Rear Elevation (3), and Left Side Elevation (4). Each view is detailed with material callouts such as laminated asphalt shingles, concrete fibre lap siding, pre-manufactured stone veneer, and aluminum gutters.

EN VIRO TEC GENERAL CONTRACTING LTD.

1 Front Elevation

Scale: 1/4" = 1'-0"

2 Right Side Elevation

Scale: 1/4" = 1'-0"

3 Rear Elevation

Scale: 1/4" = 1'-0"

4 Left Side Elevation

Scale: 1/4" = 1'-0"

development permit 102 ATKINS ROAD VIEW ROYAL B.C.

drawing # 7548 scale 1/4" = 1'0" drawn by NS

102 atkins road AMENDED DEVELOPMENT PERMIT PRESENTATION

#103 891 ATTREE AVENUE VICTORIA, B.C. V9B 0A6

PH: 250.382.7374 FAX: 250.382.7364

Date: 13/9/17

Page 26
Extracted from: 2017 10 17 Council Agenda - Agenda - Pdf
