Appendix

Attachment 12 - Development Permit 2015/12 - Front Building Elevations - Approved

October 17, 2017Page 271 section

A copy of the previously approved building elevations from 2016 for comparison purposes.

Approved Feb 02, 2016Permit # DP2015/12

BUILDING HEIGHTS

EN VIRO TEC GENERAL CONTRACTING LTD.

Architectural elevation drawings for nine residential buildings labeled Building A1 through Building C3, showing building heights, exterior materials, and facade designs.
Architectural elevation drawings for nine residential buildings labeled Building A1 through Building C3, showing building heights, exterior materials, and facade designs.

Building Height Specifications

  • Building A1: 7.21 m
  • Building A2: 7.21 m
  • Building A3: 7.21 m
  • Building B1: 7.16 m
  • Building B2: 7.16 m
  • Building B3: 7.15 m
  • Building C1: 7.16 m
  • Building C2: 7.15 m
  • Building C3: 7.13 m

DEVELOPMENT PERMIT 102 ATKINS ROAD VIEW ROYAL B.C.

Drawing Information

  • Drawing #: 7548
  • Scale: 3/16" = 1'0"
  • Drawn by: NS
  • Date: 25/1/16

VICTORIA DESIGN GROUP #103 - 891 ATTREE AVENUE VICTORIA, B.C. V9B 0A6 PH: 250.382.7374 FAX: 250.382.7364

102 atkins road DEVELOPMENT PERMIT PRESENTATION

Page 27
