Attachment 9. Amended Front Elevation / Side Elevation - 18 Fenton Road
Modified elevation drawings showing the finished exterior design for the house at 18 Fenton Road.
Architectural Elevations - Mr. & Mrs. Haymes
Amended Front Elevation
Scale: 1/4" = 1'0"
- Annotations:
- Pitch to match
Side (West) Elevation
Scale: 1/4" = 1'0"
- Annotations:
- 6/12 pitch
- Horizontal siding to match
- Stucco to match
- Existing deck
- Average Grade: 32.52m
- Height measurement from average grade: 12'-8"
Construction Details
- Flashing Detail at Post/House
- Stair/Railing Detail
- Side Railing Section
Disclaimer
As there are hundreds of calculations and dimensions that are made during the planning process, and even though a great deal of effort is made to ensure their accuracy including site checks that are performed during this process, from time to time an error(s) and/or omission(s) will occur, as it shall be the responsibility of the client, contractor and owner to verify all aspects of these plans prior to their use, and to report any discrepancies, errors or omissions immediately to the Designer. Because of the above, and because the use of these plans is not administered or controlled by the designer, it shall be understood with the acceptance of these plans, that the Designer shall be held harmless from any and all liability in regards to their use.
Project Information
- Client: Mr. & Mrs. Haymes
- Designer/Consultant: T-SQUARE Design & Consulting
- Address: 2850 Lakehurst Drive, Victoria, BC
- Phone: 250-382-2893
- Email: design@tsquare.ca
- Date: 01.09.17
- Scale: AS SHOWN
- Designed By: DL
- Drawn By: DL
- Drawing No: 187-8-5
