Attachment 5: Thetis Lake Residential Conceptual Site Plan

July 4, 2017Page 881 section

Site architectural drawing showing locations of the 4 apartment buildings and townhouse rows.

1. CALL TO ORDER
Wensley Architecture Ltd.Project: 17014

THETIS LAKE RESIDENTIAL

Conceptual site plan

Conceptual site plan for Thetis Lake Residential development featuring 4 five-storey multifamily buildings and 13 townhome blocks, with underground parking and proximity to the Trans-Canada Hwy.
Conceptual site plan for Thetis Lake Residential development featuring 4 five-storey multifamily buildings and 13 townhome blocks, with underground parking and proximity to the Trans-Canada Hwy.

Project Overview

  • 4 Five-storey buildings with 260 2B
  • 46 Townhomes

Site Statistics

  • Site Area: 559,515 SF (51.9 AC)
  • Green Space: 313,484 SF (29.1 AC) 56% of Site Area
Gross Floor Area Units / Details
Multifamily
Building A 70 UNITS
Building B 60 UNITS
Building C 70 UNITS
Building D 60 UNITS
Total Multifamily 260 Units
Townhomes
Block 1
Block 2
Block 3
Block 4
Block 5
Block 6
Block 7
Block 8
Block 9
Block 10
Block 11
Block 12
Block 13
Total Townhomes 46
Grand Total 306 Units

Map Features & Labels

  • Underground Parking Below: Located beneath Buildings A, B, C, and D.
  • Setbacks: 33'-0" (10.06m) setbacks indicated along property lines.
  • Property Line: Boundary of the development site.
  • Infrastructure: Adjacent to Trans-Canada Hwy.

Architectural Firm WENSLEY ARCHITECTURE LTD PROJECT: 17014
