Attachment 8: Proposed Development Plan (Survey Diagram)

July 4, 2017Page 911 section

Surveyor's plan illustrating the proposed five-lot subdivision and access easements.

1. CALL TO ORDER
Island Land Surveying Ltd.May 23, 2017

PROPOSED DEVELOPMENT PLAN OF LOT 1, SECTIONS 97 AND 98, ESQUIMALT DISTRICT, PLAN VIP64516

Detailed site plan for the proposed development of Lot 1, Sections 97 and 98, Esquimalt District. The plan illustrates the subdivision of the property into five proposed lots with specified areas and building footprints, situated adjacent to the Trans Canada Highway and Thetis Lake Regional Park.
Detailed site plan for the proposed development of Lot 1, Sections 97 and 98, Esquimalt District. The plan illustrates the subdivision of the property into five proposed lots with specified areas and building footprints, situated adjacent to the Trans Canada Highway and Thetis Lake Regional Park.

NOTE: Lot dimensions, areas and subdivision design are subject to vary. Existing encumbrances upon the parcel are not shown. This proposal is subject to rezoning and must be approved by approving authorities.

Proposed Subdivision Details

  • Proposed Lot 1: AREA = ±0.492 Ha (includes Building A)
  • Proposed Lot 2: AREA = ±0.442 Ha (includes Building B)
  • Proposed Lot 3: AREA = ±0.496 Ha (includes Building C)
  • Proposed Lot 4: AREA = ±0.433 Ha (includes Building D)
  • Proposed Lot 5: AREA = ±3.3 Ha

Site Context and Landmarks

  • Adjacent Lands: PT. SEC. 97, REM. 36 PLAN 748
  • Regional Features: THETIS LAKE REGIONAL PARK
  • Roadways: TRANS CANADA HIGHWAY, ROAD PLAN VIP62157
  • Boundaries: SECTION 97 and SECTION 98 boundaries indicated.

Plan Information

  • Date: May 23, 2017
  • Archive: 97-Lentona-TC-SUB1
  • Surveyor: Island Land Surveying Ltd.
  • Address: #117-593 Hoffman Avenue, Victoria B.C. V9B 4X1
  • Telephone: 250 475 1515
  • Fax: 250 475 1516
  • Website: www.islandsurveying.ca
