Main Floor Plan - 18 Fenton Road

June 6, 2017Page 281 section

Architectural floor plan for the main level of the proposed addition at 18 Fenton Road.

Project: Mr. & Mrs. HaymesDesigner: T-Square Design & Consulting

Main Floor Plan

Detailed architectural floor plan for the main level of a residence, showing room layouts for a master suite, living and dining areas, and a large covered deck, including annotations for existing structures and new additions.
Detailed architectural floor plan for the main level of a residence, showing room layouts for a master suite, living and dining areas, and a large covered deck, including annotations for existing structures and new additions.

Project Information

  • Client: Mr. & Mrs. Haymes
  • Design Firm: T-SQUARE Design & Consulting
  • Address: 2850 Lakehurst Drive, Victoria, BC
  • Drawing Number: 187-H
  • Scale: As Shown
  • Designed By: DL
  • Drawn By: DL

Floor Area Summary

Description Area (Square Feet) Area (Square Meters)
Existing Floor Area 1,216 sq. ft. 112.96 m²
Addition 1,638.88 sq. ft. 152.25 m²
Total Main Floor Plan 2,854.88 sq. ft. 265.21 m²

Plan Annotations and Room Labels

  • Master Bedroom: Features a gas fireplace with roof-mounted flue and a 1/2" x 96" makeup area.
  • Master Bathroom: Located adjacent to the master bedroom.
  • Living Rm: Includes notes for floor joists at 16" o.c.
  • Dining Rm: Note indicates "Remove exist. wall" to open the space.
  • Covered Deck: Large exterior deck area.
  • Kitchen Area: Features a central island and proximity to the dining room.
  • WIC: Walk-in closet area.
  • Scale: 1/4" = 1'-0"
Page 28
