TOWN OF VIEW ROYAL BYLAW NO. 939 - ROAD CLOSURE AND REMOVAL OF HIGHWAY DEDICATION – PART OF CHILCO ROAD
Bylaw and related plan for the formal closure and removal of highway dedication for a section of Chilco Road.
TOWN OF VIEW ROYAL BYLAW NO. 939
A BYLAW TO CLOSE TO ALL TYPES OF TRAFFIC AND REMOVE THE DEDICATION OF HIGHWAY FOR PART OF CHILCO ROAD
The Council of the Town of View Royal, in open meeting assembled, enacts as follows:
This Bylaw may be cited for all purposes as “Road Closure and Removal of Highway Dedication – Part of Chilco Road, Bylaw No. 939, 2015”.
That part of the highway shown as “Subject Area” on the plan attached to this Bylaw as Schedule “A” is hereby stopped up and closed to traffic of all kinds and the dedication of such highway is hereby removed.
The Mayor and Corporate Officer are authorized to execute all documents and plans necessary to implement the power and authority exercised by this Bylaw, and the Clerk is authorized to affix the seal of the corporation to documents and plans where necessary.
READ A FIRST TIME THIS 17th DAY OF NOVEMBER, 2015
READ A SECOND TIME THIS 17th DAY OF NOVEMBER, 2015
READ A THIRD TIME THIS 17th DAY OF NOVEMBER, 2015
APPROVED BY THE MINISTRY OF TRANSPORTATION AND INFRASTRUCTURE THIS 9th DAY OF AUGUST, 2016
ADOPTED BY COUNCIL, SIGNED BY THE MAYOR AND THE CLERK AND SEALED WITH THE SEAL OF THE TOWN OF VIEW ROYAL THIS DAY OF , 2016
MAYOR CORPORATE OFFICER
SCHEDULE “A”
REFERENCE PLAN TO ACCOMPANY THE TOWN OF VIEW ROYAL ROAD CLOSURE BYLAW No. OF PART OF CHILCO ROAD DEDICATED BY PLAN EPP55110, SECTION 98, ESQUIMALT DISTRICT, PURSUANT TO SECTION 120 OF THE LAND TITLE ACT AND SECTION 40 OF THE COMMUNITY CHARTER.
PLAN EPP55111.
LEGEND
- ● Denotes Standard Iron Post Found
- Rx Denotes short Iron Post in rock
NOTES
- BCGS 92B.043
- SCALE=1:500. All distances are in metres.
- The intended plot size of this plan is 560mm in width by 432mm in height (C Size) when plotted at a scale of 1:500.
- Grid bearings are derived from GNSS observations and are referred to the central meridian of UTM Zone 10. To obtain local astronomic bearings referred to the meridian passing through Iron Post 1, subtract 0°21'07".
- The UTM coordinates and estimated horizontal positional accuracy achieved are derived from single point positioning techniques using the Precise Point Positioning (PPP) service of Natural Resources Canada.
- This plan shows horizontal ground-level distances, unless otherwise specified. To compute grid distances, multiply ground-level distances by the average combined factor of 0.9996071. The average combined factor has been determined based on an ellipsoidal elevation of 54 metres.
This plan lies within the Capital Regional District.
The field survey represented by this plan was completed on the 27th day of August, 2015. Jason C. Kozina, BCLS 787
Island Land Surveying Ltd. 1-15 Cadillac Avenue Victoria B.C. V8Z 1T3 TEL 250.475.1515 fax 250.475.1516 www.islandsurveying.ca File: 0733-JK-97 Archive: 97-Limona-P7-RF2
