Appendix
BICYCLE FACILITIES IDEAS
June 13, 2017Page 1511 section
Visual examples of proposed resident and visitor bicycle parking and maintenance facilities.
Features: Secure resident rooms, maintenance station, visitor stations
BICYCLE FACILITIES IDEAS
Bicycle parking adjacent to assigned parking spaces
Secure resident bicycle parking rooms
Bicycle maintenance station
Visitor bicycle parking stations
Note: images are examples for illustrative purposes only. Type, finish, and technology of selected systems will vary.
| Project Information | Details |
|---|---|
| Project | CHRISTIE POINT REDEVELOPMENT PLAN - REZONING |
| Location | CRAIGOWAN ROAD, VIEW ROYAL, BC |
| Sheet Title | BICYCLE FACILITIES IDEAS |
| Date | Feb 28 2017 |
| Project No. | 1505 |
| Scale | N/A |
| Drawn by | NF |
| Chk'd by | FD |
D'AMBROSIO architecture + urbanism 2960 Jutland Road Victoria BC Canada V8T 5K2 tel 250.384.2400 fax 250.384.7893 eml mail@fdarc.ca web www.fdarc.ca
copyright reserved. these drawings and designs are and at all times remain the property of d'ambrosio architecture to be used for the project shown and may not be reproduced without written consent.
