Hand-drawn site plan provided by the applicant showing proposed deck dimensions and setbacks.

1 CALL TO ORDER
Proposes permeable deck surface

31 STONERIDGE DRIVE

Site plan for 31 Stoneridge Drive showing a "dwelling under construction" with a porch, an existing structure labeled "36", and a walkway. The plan includes property boundaries, various dimensional measurements, an 8M distance marker, and a 6m setback line.
Site plan for 31 Stoneridge Drive showing a "dwelling under construction" with a porch, an existing structure labeled "36", and a walkway. The plan includes property boundaries, various dimensional measurements, an 8M distance marker, and a 6m setback line.

Site Plan Notes

  • Deck surface will be permeable 1.5 - 2" x 6" wood or composite deck boards

Plan Details and Measurements

  • Location: 31 STONERIDGE DRIVE
  • Primary Structure: dwelling under construction
  • Additional Features:
    • porch
    • Existing structure (labeled 36)
    • WALKWAY
  • Setbacks and Reference Lines:
    • 6m SETBACK
    • 8M
  • Boundary Measurements:
    • 13.754 (Frontage)
    • 43.781
    • 19.180
    • 35.332 (Along walkway)
  • Building and Interior Measurements: 4.66, 5.87, 1.23, 1.51, 1.36, 3.19, 2.87, 3.63, 2.60, 13.72, 9.42, 3.12, 2.74, 3.18, 2.71, 2.04, 2.61, 8.84m, 10.17, 7.32m, 6.71m, 1.52m, 1.12m.
