Appendix G: Conceptual Design Layouts - Station Avenue Park and Ride

January 15, 2019Pages 134–1372 sections

Conceptual engineering sketches (01X, 02X, 03X) for the Station Avenue Park and Ride facility in Langford.

1 CALL TO ORDER
Capacity: 141 regular stalls, 4 disable accessible stallsDate: 2018/07/13Project # 652113

Island Highway Transit Priority Plan and Park & Ride Study

Final Report

BC Transit
July 2018

Page 134–137

Appendix G – Concept Park & Ride Layouts

Station Avenue Park and Ride, Langford - Conceptual Design (Sketch 01X)

Aerial view showing the western end of the conceptual layout for the Station Avenue Park and Ride at Phipps Road
Aerial view showing the western end of the conceptual layout for the Station Avenue Park and Ride at Phipps Road
Aerial view showing conceptual parking stalls along the E&N Railway near Aprell Place
Aerial view showing conceptual parking stalls along the E&N Railway near Aprell Place

Project Information:

  • Project: BC Transit: Island Hwy Transit Priority Plan
  • Location: Station Avenue Park and Ride, Langford
  • Project Number: #652113
  • Sketch Number: 01X
  • Status: Progress Print - Preliminary For Information Only (2018-07-30)
  • Designed: H. Kambo (2018/07/13)
  • Reviewed: T. Stevens (2018/07/13)

Station Avenue Park and Ride Site Data:

  • 141 Regular Stalls (Typ. Stall Size: 2.8 m x 5.4 m)
  • 4 Disable Accessible Stalls

Layout Labels and Dimensions:

  • Phipps Road
  • Station Avenue
  • Aprell Place
  • E&N Railway
  • E&N Rail Trail
  • Fence
  • Disabled
  • 8.40
  • 6.8 Two-Way Aisle
  • 5.4 Stall
  • 0.5 Shy Distance
  • 1.80 Sidewalk
  • 3.0 Lane (Ex.)

Station Avenue Park and Ride, Langford - Conceptual Design (Sketch 02X)

Aerial view showing the central section of the conceptual Park and Ride layout adjacent to the Royal Canadian Legion and Alexander Mackie Retirement Community
Aerial view showing the central section of the conceptual Park and Ride layout adjacent to the Royal Canadian Legion and Alexander Mackie Retirement Community
Aerial view showing parking stall configurations along Station Avenue and the E&N Railway
Aerial view showing parking stall configurations along Station Avenue and the E&N Railway

Project Information:

  • Project: BC Transit: Island Hwy Transit Priority Plan
  • Location: Station Avenue Park and Ride, Langford
  • Project Number: #652113
  • Sketch Number: 02X
  • Status: Progress Print - Preliminary For Information Only (2018-07-30)
  • Designed: H. Kambo (2018/07/13)
  • Reviewed: T. Stevens (2018/07/13)

Station Avenue Park and Ride Site Data:

  • 141 Regular Stalls (Typ. Stall Size: 2.8 m x 5.4 m)
  • 4 Disable Accessible Stalls

Layout Labels and Dimensions:

  • Station Avenue
  • Royal Canadian Legion
  • Alexander Mackie Retirement Community
  • E&N Railway
  • E&N Rail Trail
  • Fence
  • 8.40
  • 6.8 Two-Way Aisle
  • 5.4 Stall
  • 0.5 Shy Distance
  • 1.80 Sidewalk
  • 3.0 Lane (Ex.)

Station Avenue Park and Ride, Langford - Conceptual Design (Sketch 03X)

Aerial view showing the eastern end of the conceptual Park and Ride layout at the intersection of Veterans Memorial Parkway and Millstream Road
Aerial view showing the eastern end of the conceptual Park and Ride layout at the intersection of Veterans Memorial Parkway and Millstream Road

Project Information:

  • Project: BC Transit: Island Hwy Transit Priority Plan
  • Location: Station Avenue Park and Ride, Langford
  • Project Number: #652113
  • Sketch Number: 03X
  • Status: Progress Print - Preliminary For Information Only (2018-07-30)
  • Designed: H. Kambo (2018/07/13)
  • Reviewed: T. Stevens (2018/07/13)

Station Avenue Park and Ride Site Data:

  • 141 Regular Stalls (Typ. Stall Size: 2.8 m x 5.4 m)
  • 4 Disable Accessible Stalls

Layout Labels and Dimensions:

  • Station Avenue
  • Veterans Memorial Parkway
  • Millstream Road
  • Langford Station
  • E&N Railway
  • E&N Rail Trail
  • Disabled
  • Fence
  • 8.40
  • 6.8 Two-Way Aisle
  • 5.4 Stall
  • 0.5 Shy Distance
  • 1.80 Sidewalk
  • 3.0 Lane (Ex.)
