Conceptual Design Sketches - Luxton Park and Ride

January 15, 2019Pages 139–1401 section

Conceptual engineering sketches (01X, 02X) for the Luxton Park and Ride facility in Langford.

1 CALL TO ORDER

Capacity: 91 stalls (incl. 2 small), 2 disable accessible stallsDate: 2018/07/13Location: Luxton Park and Ride, Langford

BC TRANSIT: ISLAND HWY TRANSIT PRIORITY PLAN

LUXTON PARK AND RIDE, LANGFORD

CONCEPTUAL DESIGN - PROJECT #652113 - SKETCH 01X

PROGRESS PRINT FOR COORDINATION ONLY – NOT AN OFFICIAL ISSUE DATE: 2018-07-30

Role	Name	Date
DESIGNED	H. KAMBO	2018/07/13
REVIEWED	T. STEVENS	2018/07/13

Scale: 1:500

STATION AVENUE PARK AND RIDE:

91 STALLS (INCL. 2 SMALL) (TYP. STALL SIZE: 2.8 m x 5.4 m)
2 DISABLE ACCESSIBLE STALLS

Map Features:

HIGHWAY 14
POSTED SPEED 60 km/h
Lane Dimensions: 3.6 m, 3.3 m
FENCE

Aerial view of the Highway 14 corridor showing residential context and preliminary lane markings.

CONCEPTUAL DESIGN - PROJECT #652113 - SKETCH 02X

PROGRESS PRINT FOR COORDINATION ONLY – NOT AN OFFICIAL ISSUE DATE: 2018-07-30

Role	Name	Date
DESIGNED	H. KAMBO	2018/07/13
REVIEWED	T. STEVENS	2018/07/13

Scale: 1:500

STATION AVENUE PARK AND RIDE:

91 STALLS (INCL. 2 SMALL) (TYP. STALL SIZE: 2.8 m x 5.4 m)
2 DISABLE ACCESSIBLE STALLS

Map Features and Labels:

RONALD ROAD
HIGHWAY 14 SOOKE ROAD
EXISTING BUS PLATFORM
POSTED SPEED 60 km/h
FIREHALL CREEK
GALLOPING GOOSE TRAIL
1.8 SIDEWALK
Roadway Lane Dimensions: 3.6, 3.3, 3.6, 3.3, 3.0
Parking and Aisle Dimensions: 4.0 (TYP.), 7.0 (TYP.)
DISABLED (parking area)
FENCE

Conceptual layout overlay on an aerial photograph showing the design for the Luxton Park and Ride parking lot and its connection to the surrounding road and trail network.
