Attachment 4: Proposed Exterior Treatment

ERSKINE LANE RE-DEVELOPMENT

PROPOSED EXTERIOR TREATMENT

7 ERSKINE LANE, TOWN OF VIEW ROYAL, B.C. SCALE: NTS 2017-05 DEVELOPMENT PERMIT 2021-01-27

1. Ceraclad Cladding – Zen Garden “Charcoal”
2. Flashing—Gentek Iron Ore
3. Hardie Panel – Arctic White smooth finish
4. Hardie Plank – Fisher Truegrain Series “Cedartone”
5. Hardie Board/Plank Painted – To match Kaycan Charcoal Metal Facia
6. Metal Facia – Kaycan Charcoal
7. Storefront Door/Glazing – Black Frame
8. Metal Door – To match Kaycan Charcoal Metal Facia
9. Security Grille – Black
10. Vinyl Window – White Frame
11. Vinyl Window – Black Frame
12. Glazed Aluminium Guards – Black with clear glass
13. Picket Aluminium Guards – Black
14. Glazed Aluminium Privacy Screen – Frosted glass

This document has been digitally certified with digital certificate and encryption technology authorized by the Architectural Institute of BC and the Engineers and Geoscientists BC. The authoritative original has been transmitted to you in digital form. Any printed version can be relied upon as a true copy of the original when supplied by the architect, bearing images of the professional seal and digital certificate, or when printed from the digitally-certified electronic file provided by the architect.
