Site Plan of Lot 3, Block 1, Section 9, Esquimalt District, Plan 1430

May 19, 2020Page 931 section

A professional survey and site plan for 8 Eaton Avenue showing existing structures and the proposed accessory building location.

1 CALL TO ORDER
Survey completed February 24, 2020Proposed new accessory building: 28.40 m²Max height: 4267 mm from existing asphalt

SITE PLAN OF LOT 3, BLOCK 1, SECTION 9, ESQUIMALT DISTRICT, PLAN 1430

Site plan map showing Lot 3 at the corner of Eaton Avenue and Burnside Road, including proposed accessory building, existing structures, driveway, and various elevations.
Site plan map showing Lot 3 at the corner of Eaton Avenue and Burnside Road, including proposed accessory building, existing structures, driveway, and various elevations.

LEGEND

  • + 98.45 DENOTE SPOT ELEVATION
  • TREE - CONIFEROUS
  • TREE - DECIDUOUS

SITE NOTES

  • LOCATION OF EXISTING CONCRETE FOUNDATION
  • PROPOSED NEW ACCESSORY BUILDING
  • TOTAL SQUARE METERS = 28.40 M²
  • MAXIMUM HEIGHT AT RIDGE = 4267 mm FROM EXISTING ASPHALT SURFACE
  • ROOF DESIGN BASED ON SNOW LOAD OF 1.5 kPa.
  • PLAN VIP66599

PROJECT INFORMATION
PREPARED FOR: TROY CARTER
PID NO.: 005-520-851
CIVIC ADDRESS: 8 EATON AVENUE, ESQUIMALT, BC
DRAWING NUMBER: 2241-20511-V-0-SK

ADDITIONAL INFORMATION

  • SCALE 1 : 200
  • ALL DISTANCES ARE IN METRES AND DECIMALS THEREOF
  • SURVEY COMPLETED FEBRUARY 24, 2020
  • ELEVATIONS ARE GEODETIC AND REFERENCED TO GCM # 80H3083, ELEVATION: 27.552
  • THIS PROPERTY MAY BE SUBJECT TO THE FOLLOWING RIGHT OF WAY J8639, ED85293

THIS BUILDING LOCATION CERTIFICATE HAS BEEN PREPARED IN ACCORDANCE WITH THE PROFESSIONAL REFERENCE MANUAL AND IS CERTIFIED CORRECT ACCORDING TO LAND TITLE AND SURVEY AUTHORITY RECORDS AND FIELD SURVEYS. UNREGISTERED INTERESTS HAVE NOT BEEN INCLUDED OR CONSIDERED. CERTIFIED CORRECT THIS 18th DAY OF MARCH, 2020.

THIS PLAN IS PREPARED SOLELY FOR A LIMITED CONTRACTUAL USE BETWEEN MCELHANNEY ASSOCIATES AND OUR CLIENT. THIS DOCUMENT SHOWS THE RELATIVE LOCATION OF THE SURVEYED STRUCTURES AND FEATURES WITH RESPECT TO THE BOUNDARIES OF THE PARCEL DESCRIBED ABOVE. THIS DOCUMENT SHALL NOT BE USED TO DEFINE PROPERTY LINES OR PROPERTY CORNERS. THE SIGNATORY ACCEPTS NO RESPONSIBILITY OR LIABILITY FOR ANY DAMAGES THAT MAY BE SUFFERED BY A THIRD PARTY AS A RESULT OF ANY DECISIONS MADE, OR ACTIONS TAKEN BASED ON THIS DOCUMENT.

McElhanney Associates Land Surveying Ltd. Suite 500, 3960 Quadra Street Victoria BC, Canada V8X 4A3 Tel 250 370 9221
