Council Meeting/Documents/Appendix 4: Architectural Drawings - 17 Eaton Avenue
Appendix

Appendix 4: Architectural Drawings - 17 Eaton Avenue

November 3, 2020Pages 32–343 sections

Building plans and elevations showing the proposed and existing structures at 17 Eaton Avenue.

1 CALL TO ORDER
17 Eaton AvenueDrawings show 'Open area under main floor' and garage dimensions

Appendix 4

3D architectural rendering of the proposed residence
3D architectural rendering of the proposed residence

250-208-0196

NO SUITES PERMITTED

Ruhi Manshadi 17 Eaton Avenue Victoria BC

New Residence

COVER SHEET

Page 32–34

South Elevation

Architectural south elevation drawing showing building exterior details and grid lines 1 through 7
Architectural south elevation drawing showing building exterior details and grid lines 1 through 7

Notes:

  • GUARDRAIL
  • OPEN TO NORTH SIDE YARD
  • SUPPORT COLUMN - SEE STRUCTURAL
Page 32–34

Floor Plan

Detailed architectural floor plan showing interior layout and site dimensions
Detailed architectural floor plan showing interior layout and site dimensions

Room Labels and Details:

  • OPEN AREA UNDER MAIN FLOOR (40% UNENCLOSED)
  • GARAGE: 44.8 SQ M (482 S.F.)
  • BATH: 5-0 x 7-4
  • BEDROOM: 14-6 x 10-6
  • DEN: 17-2 x 12
  • NO SUITES PERMITTED

General Notes and Annotations:

  • BEAM OVER - SEE STRUCT
  • GUARDRAIL
  • COLUMN - SEE STRUCTURAL
  • PROPERTY LINE
  • TREE
  • NOTE: CHANGE OF WALL TYPE MAINTAIN CONTINUOUS EXTERIOR WALL PLANE

Site Dimensions (mm):

  • 6854
  • 3667
  • 2363
  • 4794
  • 7081
  • 5486
  • 5159
  • 12192
  • 7010
  • 5182
  • 6344
  • 3905
  • 1943
  • 1548
  • 10825
Page 32–34
