Architectural Drawings (Duplicate)

November 3, 2020Pages 54–561 section

Duplicate architectural drawings for 17 Eaton Avenue provided by legal counsel.

1 CALL TO ORDER
Ruhi ManshadiProposed new residence plans

Appendix 4

Cover Sheet

Ruhi Manshadi 17 Eaton Avenue Victoria BC New Residence

Project Number: 250-208-0186

Note: NO SUITES PERMITTED

No. Description
1 ISSUED FOR NEW DEVELOPMENT PERMIT
3D perspective rendering of the proposed new residence
3D perspective rendering of the proposed new residence

South Elevation

South elevation architectural drawing showing structural columns, guardrails, and window configurations
South elevation architectural drawing showing structural columns, guardrails, and window configurations

Key Labels:

  • GUARDRAIL
  • SUPPORT COLUMN - SEE STRUCTURAL

Floor Plan

Ground floor architectural plan detailing room layouts, dimensions, and property setbacks
Ground floor architectural plan detailing room layouts, dimensions, and property setbacks

Room Details and Dimensions:

  • Open Area Under Main Floor: (40% Unenclosed)
  • Garage: 44.8 SQ M (482 S.F.)
  • Bath: 5-0 x 7-4
  • Bedroom: 14-6 x 10-6
  • Den: 17-2 x 12

General Notes and Labels:

  • NO SUITES PERMITTED
  • 7500 SETBACK
  • COLUMN - SEE STRUCTURAL
  • BEAM OVER
  • BEAM OVER SEE STRUCT.
  • GUARDRAIL
  • PROPERTY LINE
  • TREE
