Proposed Subdivision for Ms. Ruhi MANSHADI

November 3, 2020Page 591 section

Site plan and FSR calculation sheet for 17 Eaton Avenue.

1 CALL TO ORDER
Total Site Area: 5712 sfProposed GFA: 2570 sfProposed FSR: 0.45

Proposed Subdivision for: Ms. Ruhi MANSHADI

#17 Eaton Ave, View Royal, BC

Location map and aerial photograph collage showing the site at 17 Eaton Ave and the surrounding neighborhood
Location map and aerial photograph collage showing the site at 17 Eaton Ave and the surrounding neighborhood

Site Plan with new lot area- Each lot 530.6 sm

Project Data for Proposed Lot B:

Category Details
Present Zoning R1-A
Proposed Zoning CD 7
Site Area 5712 sf (530.6 sm)
Proposed Site Coverage 2030 sf = 35.5%
Floor Areas Proposed FAR 0.45 = 238.77 sm = 2570 sf
Upper 1040 sf
Ground 1126 sf
Garage 404 sf
Carport 0 sf
GFA Total 2570 sf = 0.45 FAR

Building Height:

  • Max permitted: 7.5 m (24.6')
  • Height Proposed: 7.5 m (24.6')

Project Data for Proposed Lot A:

Category Details
Present Zoning R1-A
Proposed Zoning CD 7
Site Area 5712 sf (530.6 sm)
Proposed Site Coverage 827 + 210 + 410 sf = 1447 sf = 25.3%
Existing Floor Area 827 sf
Proposed FAR 0.45 = 238.77 sm = 2570 sf

Building Height:

  • Max permitted: 7.5 m (24.6')
  • Height Proposed: 7.5 m (24.6')

Revisions:

  • REV 05 (16 MAY 2011): New floor plans to meet 0.45 FAR
  • REV 04 (02 MAY 2011): Amend New Property Line to equalize lot areas, both 530.6sm
  • REV 03 (04 APR 2011): Amend Design for client, Amend FAR, GFA & Site Covg, add dr phase
