Minutes of the Joint Advisory Committee Meeting held October 27, 2020

Sheet L 1: Conceptual Landscape Plan

Project: WESTURBAN DEVELOPMENTS, Erskine Lane Date: May 10, 2020 Scale: 1:350 METERS Drawn By: LS/SD

Revisions

[Map: Conceptual Landscape Plan of the full Erskine Lane development site, including buildings A, B, C, and D, with detailed landscaping, pathways, and property boundaries.]

Plan Annotations and Site Features

• HIDDEN COURTYARD: WITH RAISED PLANTERS, BUILT IN SEATING & SMALL LAWN
• CORTEN SCREEN: ALONG PARKING FEATURE IN COBBLE ROCK BASE
• BUILDING A: 5 STOREY (79 UNITS), 29 MFE
• BUILDING B: 5 STOREY (79 UNITS), 29 MFE
• MAIN ENTRY (Identified at Building A, B, C, and D)
• COVERED BIKE SHELTER
• BLEND DISTURBANCE EDGE TO FOREST: WITH LOW GROWING NATIVE SHRUBS & GROUNDCOVERS
• DOG RUNS: FULLY FENCED WITH SELF CLOSING GATE, TRANSFER AREA, WATER SOURCE, KENNEL SHELTERS
• CHILDRENS PLAY EQUIPMENT: ON ACCESSIBLE SURFACE (EWF OR RUBBER TILE)
• OPEN LAWN GRASS PLAY AREA: TO CREATE PARK LIKE SPACE WHICH, BACKS ONTO RETAINED FOREST
• BUILDING D: 5 STOREY (89 UNITS), 21 MFE
• BUILDING C: 5 STOREY (89 UNITS), 21 MFE
• GAZEBO SHELTER: OVERLOOKING LAWN AND ENTRY COMMON COURTYARD WITH VIEW LINES TO BOTH BUILDINGS MAIN ENTRANCES
• RAISED PLANTER WITH SEATING (ON SLAB)
• RESIDENT GARDENING CORNER: 2' x 2' x 4' & 2' x 2' x 6' ALUMINUM HORSE TROUGH CONTAINERS SET ON CRUSH GRAVEL SURFACE OVER PARKING SLAB. CHAIN LINK FENCE SURROUND FOR FALL & DEER PROTECTION.
• RETAINING WALLS WITH TIERED PLANTING: ROCK WALLS PLANTED WITH SUN LOVING VINES & EVERGREEN SHRUB FACING MAIN ROAD VIEWS. ROUGH CEDAR FENCE FALL PROTECTION FOR ALONG TOP OF WALLS, AS REQUIRED.
• DISCOVERY NATURE WALK: (THIS IDEA COULD BE INCORPORATED INTO BOTH SITES)
• POTENTIAL GRAVEL SURFACE WALKING TRAIL: WINDING THROUGH FOREST - TO BE SITE FIT WITH ARBORIST SUPERVISION TO ENSURE NO DAMAGE IS DONE TO TREES - TO PROVIDE ACCESS FOR EXPLORATION PLAY & DISCOVERY.
• HEALING GARDEN: SELECTION OF PERENNIAL HERBS & MEDICINAL PLANTS IN FEATURE FRONT GARDEN, SOME OPEN DIRT PLOT SPACES AVAILABLE FOR RESIDENT GARDENING
• RETAINING WALLS WITH TIERED PLANTING: SHADY NATIVE SHRUBS BETWEEN TIERED ROCK WALLS BLENDING INTO EXISTING SLOPES & NATIVE FOREST WHERE POSSIBLE
• WALKWAY ACCESS: 1.5 METER WIDE CONCRETE WALKWAY FOR ACCESS
• RAISED PLANTERS ON COBBLE ROCK: AGAINST GROUND FLOOR UNITS
• RAISED METAL PLANTERS: 24" x 72" PREFAB METAL PLANTER BOXES SET ON SLAB ALONG GROUND FLOOR UNITS TO PROVIDE SCREENING
• SMALL COVERED SEATING AREA: OVERLOOKING NATURE PARK, AT BACK OF GARBAGE ENCLOSURE
• EXISTING NATURAL PATHWAY THROUGH FOREST
• TRAIL CONNECTION: POSSIBLE LOCATION FOR GRAVEL PATH ACCESS TO EXISTING TRAIL IN ROW
• LOT A and LOT B
• WATKISS WAY and ERSKINE LANE
• ROW (Right of Way)
• RETAINED EXISTING VEGETATION (Multiple designated areas)

LEGEND

• Property Line
• Setback Line (Building Envelope)
• Underground Parkade
• CS (Brushed Concrete): Patterns TBD - Refer to Civil Eng. Dwgs.
• Proposed ROW Sidewalk: Refer to Civil For Details
• Compacted 3/4" Crush Rock: For Informal Walkways & Dog Runs
• Planting Beds: cw 60 mm Bark Mulch on Filter Fabric on Approved Growing Medium At Specified Depths (450 mm minimum For Shrubs & 750 mm minimum For Trees) For both on and off slab conditions
• Sedum Feature Planting Display: cw 150 mm Depth Approved Growing Medium On Slab.
• LAWN: Seeded Lawn Areas cw 150 mm Min. Depth of Approved Growing Medium
• Existing Vegetation Area To Be Retained
• Decorative (1" - 3") Washed Round Cobble Rock Groundcover: Sized Cobble TBD With Detailed Design To Coordinate With On Slab Drainage
• Feature Decorative Boulders: as Locally Available & Sourced From Site Size Range 600mm - 1200mm
• Boulder Rock Stack Retaining Walls: Utilizing Rock From Site *Refer to Eng. For Final Wall Design, Location & Details
• Black Vinyl Coated Chain Link Fence: 5' Ht.
• Rough Cedar Wood Fence / Fall Protection: 4' Ht.
• PTW Privacy Fence: 6' Ht.
• Raised Planters Over Underground Parking On Slab (3 Types):
  1. Powder Coated Metal Style, Insulated for 4 Season Planting - Approx Size 24" x 72"
  2. CIP Concrete Tree Planter, Insulated for 4 Season Planting - Approx Size 1.2m x 2.5m (1 m ht.)
  3. Aluminum Horse Trough Vegetable Garden Planters - 2 Sizes - 2' x 2' x 4' & 6' Set On Crush Gravel On Slab
• Bench Seating: Wood or Wood Composite Construction
• Bike Racks: Dero Rolling Rack or Approved Equivalent Colour TBD to Complement Building Character
• Decorative Screen Feature: With Semi Transparent Style For Screening Between Parking & Mini Plaza Spaces
• Light Bollard or Interpretive Signage: 36" Height
• Bench Feature Style & Colour TBD
• Existing Contours For Reference Only
• Proposed New On Site Trees: TOTAL PROPOSED 238
• Proposed New Trees in ROW: TO BE APPROVED BY CITY - TOTAL PROPOSED 12
• Waypoint ID Pin (Green Circle): For Existing Trees To Be Retained If Possible INSIDE & OUTSIDE BUILDING ENVELOPE. TOTAL ID PINS TO BE RETAINED 130.
• Waypoint ID Pin (Red X): For Existing Trees To Be Removed OUTSIDE BUILDING ENVELOPE.
