Council Meeting/Documents/APPENDIX A SITE PLAN - FIGURE 1
Appendix

APPENDIX A SITE PLAN - FIGURE 1

November 3, 2020Pages 212–2132 sections

The proposed engineering site plan showing building layouts (Buildings A through D) and parking for 9 Erskine Lane.

1 CALL TO ORDER
October 9, 2019Buildings A, B, C, D identified

APPENDIX A

Page 212–213

SITE PLAN - FIGURE 1

Appendix A cover page for Site Plan - Figure 1
Appendix A cover page for Site Plan - Figure 1

OCTOBER 2, 2019 FOR DISCUSSION PURPOSES ONLY

CIVIC ADDRESS: 9 ERSKINE LANE LOT B TOWN OF VIEW ROYAL, PLAN VIP26648

9 ERSKINE LANE SITE PLAN - FIGURE 1

TOWN OF VIEW ROYAL

IEL PROJECT: 2253 ISSUED: OCT 09, 2019 DRAWN BY: KK CHECKED BY: MJA SCALE: 1:750

The site plan illustrates the layout of the proposed development at 9 Erskine Lane:

  • BLDG A: 79 UNITS
  • BLDG B: 79 UNITS
  • BLDG C: 107 UNITS
  • BLDG D: 107 UNITS

Infrastructure and Property Labels:

  • Roadways: Watkiss Way, Erskine Lane, Strata-Erskine Lane, and Game Road (Owned by CRD).
  • Property Parcels: Lot 22, Lot 20, Lot 14, and Lot 10.
  • Site Orientation: North and South indicators.
  • Topography: Contour lines at elevations 30.00, 25.00, and 20.00.
Page 212–213
