Council Meeting/Documents/Site Location Plan (Drawing 8298-3-1)
Appendix

Site Location Plan (Drawing 8298-3-1)

November 3, 2020Page 3541 section

An aerial location plan map showing the proposed site at 9 Erskine Lane relative to Watkiss Way, Hospital Way, and the Trans-Canada Highway.

1 CALL TO ORDER
9 Erskine LaneWesturban Developments Ltd.July 2019

LOCATION PLAN

Proposed 5-6 Story Building

9 Erskine Lane, View Royal, B.C.

Geotechnical location plan map showing the site at 9 Erskine Lane. The map features an aerial photograph with overlays for property lines, bedrock surface areas (Site Class 'A'), and inferred clay deposit areas (Site Class 'C'). Surrounding landmarks include Victoria General Hospital, Hospital Way, Watkiss Way, Erskine Lane, and the Trans-Canada Highway. Specific geotechnical features such as rock cuts and walls are labeled with their heights.
Geotechnical location plan map showing the site at 9 Erskine Lane. The map features an aerial photograph with overlays for property lines, bedrock surface areas (Site Class 'A'), and inferred clay deposit areas (Site Class 'C'). Surrounding landmarks include Victoria General Hospital, Hospital Way, Watkiss Way, Erskine Lane, and the Trans-Canada Highway. Specific geotechnical features such as rock cuts and walls are labeled with their heights.

LEGEND:

  • Bedrock at surface - Site Class 'A'
  • Inferred Clay Deposit - Site Class 'C'

Notes:

Base imagery obtained from CRD Webmap 2017 aerial photography.
Client Westurban Developments Ltd.
Drawn SJB
Date July, 2019
Scale 1:2950
Drawing No. 8298-3-1
Company RYZUK GEOTECHNICAL Engineering & Materials Testing

Map Labels:

  • Victoria General Hospital
  • Rock Cuts (3-4 m high)
  • Rock Wall (8-10 m high)
  • Cut Slope (8-10 m high)
  • Hospital Way
  • Watkiss Way
  • Erskine Lane
  • Property Line
  • Victoria Water Main Right of Way
  • TRANS-CANADA HWY
Page 354
