Maps, orthophotos, and signage renderings for the commercial building at 101 Presley Place.

1. CALL TO ORDER
12m tenant frontageGraphic FX Signs renderings

Subject Property Map - 101 Presley Pl

Detailed map showing property boundaries and parcel numbers for 101 Presley Pl and surrounding roads including Six Mile Road, Trans Canada Highway, and Nursery Hill Drive.
Detailed map showing property boundaries and parcel numbers for 101 Presley Pl and surrounding roads including Six Mile Road, Trans Canada Highway, and Nursery Hill Drive.
Page 81–84

101 Presley Place - Subject Property Orthophoto

Aerial orthophoto of the subject property showing construction progress and property line overlays with building unit numbers 101, 111, 121, 131, and 430.
Aerial orthophoto of the subject property showing construction progress and property line overlays with building unit numbers 101, 111, 121, 131, and 430.
Page 81–84

Signage Proposal - 131 Presley Place

Lakeside Massage Therapy Sign Specifications (A & C)

  • Dimensions: 3.66 m (width) x 1.22 m (height)
  • Total Area: 4.45 m²
  • Letter Height: 10.75" (.27m)

TENANT Sign Specifications (B)

  • Dimensions: 3.66 m (width) x 1.22 m (height)
  • Total Area: 4.45 m²
  • Letter Height: To not exceed 15" (.38m)

Construction Details

  • 4" Deep, LED illuminated, plexi push through aluminum sign box.
  • Painted customer approved colour.
  • Translucent vinyl applied to plexi.

Frontage and Placement Details

Building frontage photo of unit 2-131 Presley Pl showing proposed TENANT sign location.
Building frontage photo of unit 2-131 Presley Pl showing proposed TENANT sign location.
Building frontage photo of unit 2-131 Presley Pl showing proposed TENANT sign location.
Building frontage photo of unit 2-131 Presley Pl showing proposed TENANT sign location.
  • Unit 2-131 Presley Pl:
    • 12m Tenant Frontage
    • Sign bottom height: 3.4m (134") to grade
Building frontage photo of units 3-131 and 4-131 Presley Pl showing proposed Lakeside Massage Therapy and TENANT signage locations.
Building frontage photo of units 3-131 and 4-131 Presley Pl showing proposed Lakeside Massage Therapy and TENANT signage locations.
  • Unit 3-131 Presley Pl:
    • 8.68m Tenant Frontage
    • Sign bottom height: 3.63m (143") to grade
  • Unit 4-131 Presley Pl:
    • 7.62m Tenant Frontage
Satellite map marking business locations including Lakeside Massage Therapy, Seriously Creative, and Pop! Frozen Yogurt near the intersection of Six Mile Rd and Presley Place.
Satellite map marking business locations including Lakeside Massage Therapy, Seriously Creative, and Pop! Frozen Yogurt near the intersection of Six Mile Rd and Presley Place.
Page 81–84

Building Frontage Comparison

Existing

Photo showing the existing building exterior with Urban Ground Market signage.
Photo showing the existing building exterior with Urban Ground Market signage.

Proposed Signage

Photo mockup showing the building exterior with proposed additional tenant signage for Lakeside Massage Therapy and generic TENANT placeholders.
Photo mockup showing the building exterior with proposed additional tenant signage for Lakeside Massage Therapy and generic TENANT placeholders.
Page 81–84

Document Images

(1)
Inset map showing the regional location of the subject property within the Capital Regional District.

Inset map showing the regional location of the subject property within the Capital Regional District.
