Appendix

Attachment 4 - 275 Plowright Road - Deck Plan

July 3, 2018Page 331 section

Technical construction drawing showing the plan view and dimensions of the proposed deck extension.

Beam and joist specifications

275 Plowright Road - Deck Plan

Hand-drawn architectural sketch of a deck plan for 275 Plowright Road. The plan shows a deck structure with sections measuring 10 feet and 9 feet in length, and a width of 9 feet. It features a set of stairs labeled "4 STEPS" with an "8" RISE" and "11 ½" RUN", with a width of 30". Construction notes specify "JOISTS 2"x8" @ 20"" and "BEAMS 3 - 2"x8" SUPPORTED BY JOIST HANGERS AND CLEATS". The deck is positioned adjacent to an "EXISTING SHED".
Hand-drawn architectural sketch of a deck plan for 275 Plowright Road. The plan shows a deck structure with sections measuring 10 feet and 9 feet in length, and a width of 9 feet. It features a set of stairs labeled "4 STEPS" with an "8" RISE" and "11 ½" RUN", with a width of 30". Construction notes specify "JOISTS 2"x8" @ 20"" and "BEAMS 3 - 2"x8" SUPPORTED BY JOIST HANGERS AND CLEATS". The deck is positioned adjacent to an "EXISTING SHED".

Plan Specifications:

  • Steps: 4 steps, 8" rise, 11 ½" run, 30" width.
  • Joists: 2" x 8" at 20" intervals.
  • Beams: Three 2" x 8" beams supported by joist hangers and cleats.
  • Dimensions: Two sections measuring 10' and 9' in length; total width of 9'.
  • Site Context: Located next to an existing shed.

275 PLOWRIGHT ROAD - DECK PLAN

Page 33
