Attachment 5 - 275 Plowright Road - Deck Elevation

July 3, 2018Page 341 section

Detailed elevation drawing of the proposed deck, including materials and structural components.

Materials: Polycarbon roofing, cedar battensMax height: 10'-0"

275 Plowright Road - Deck Elevation

Technical drawing showing the side elevation of a deck structure with dimensions and component labels.
Technical drawing showing the side elevation of a deck structure with dimensions and component labels.

Specifications

  • Roofing: 26" x 10' Polycarbon
  • Roof Framing: 2x6 @ 24" o/c
  • Roof Pitch: 3.33, 15.5°
  • Rail: 2x10 (Horizontal)
  • Battens: 3/4 x 4 Cedar Slats (Not Climbable)
  • Decking: 5/4 x 6 Cedar
  • Joists: 2x8 @ 20" o/c
  • Beams: 2x8
  • Posts: 6x6

Dimensions and Features

  • Total Height (from Grade to Roof): 10'-0"
  • Upper Structure Height (from Deck to Roof): 7'-6"
  • Lower Structure Height (from Grade to Deck): 6'-6"
  • Railing Height: 42"
  • Foundation: Concrete Foundations
  • Base: Existing Concrete Slab
  • Support: Cross Bracing
  • Terrain: Grade indicated with slope mapping
