Appendix
Attachment 7 - 275 Plowright Road - Potting Shed Elevation
July 3, 2018Page 361 section
Drawing showing the design and dimensions of the proposed potting shed.
Materials: Hardie Board, Polycarbonate panelsDimensions: 8 ft height
275 PLOWRIGHT ROAD - POTTING SHED
Specifications and Materials:
- Overall Dimensions: 8 ft. (width) x 8 ft. (height)
- Roof:
- Material: Corrugated Polycarbonate (5 ft. span)
- Pitch: 1.5:12, 12.5%
- Framing: 2" x 6" Joists @ 24" OC
- Wall Construction:
- Upper Panels: Clear Polycarbonate Panels
- Lower Panels: Hardie Board (White)
- Framing Members: 2 x 4" x 4"
- Trim: Battens (Black)
Page 36
