Pawlak Residence - Site Plan

July 3, 2018Page 501 section

Draft site plan showing the location of the existing building, deck, and the proposed new masonry wall.

Designer: Matthew BerginkScale: 1:100

Site Plan: Pawlak Residence

Project: 4 Gonemors Point Road, Town of View Royal, BC
Drawing Title: Site Plan
Design / Drawn by: MDB
Scale: 1:100
Drawing Number: A1.0

Revision History

No. Date Description
1 2021/07/08 ISSUED FOR PERMIT
Site plan for 4 Gonemors Point Road showing the footprint of the existing building, deck, and patio, along with existing landscaping such as hedges and steps. The plan specifies the location of a proposed new masonry wall with a 1070mm high guard rail and indicates a 15m setback from the high water mark.
Site plan for 4 Gonemors Point Road showing the footprint of the existing building, deck, and patio, along with existing landscaping such as hedges and steps. The plan specifies the location of a proposed new masonry wall with a 1070mm high guard rail and indicates a 15m setback from the high water mark.

Plan Annotations

  • Existing Building
  • Existing Deck
  • Existing Patio
  • Existing Hedge
  • Existing Landscape Steps
  • Approximate location of the top of existing boulder wall
  • New masonry wall c/w 1070 high guard rail to be selected by owners, built on the toe of the existing boulder wall
  • Approximate 15m setback from high water mark
