Pawlak Residence - Elevation Drawing

July 3, 2018Page 511 section

Technical drawing showing the side profile (elevation) of the house and the proposed wall height.

Proposed wall height: ±2400mm

Pawlak Residence

Project: 4 Governors Point Road, Town of View Royal, BC Client: Pawlak Residence

Project Information

  • Drawing Title: Elevation
  • Design / Drawn by: MDB
  • Scale: 1:100
  • Drawing Number: A2.0
  • Contact: Matthew Bergink, AutoCad Technician (Tel: 250.532.6548, Email: mbergink@gmail.com)

Issues / Revisions

no. date for
1 2018/09/06 ISSUED FOR PERMIT
Architectural elevation drawing of the Pawlak Residence featuring an existing house, hedges, landscape steps, and a proposed new masonry wall with a 1070 high guard rail. Dimensioned heights are shown for various sections of the wall and terrain.
Architectural elevation drawing of the Pawlak Residence featuring an existing house, hedges, landscape steps, and a proposed new masonry wall with a 1070 high guard rail. Dimensioned heights are shown for various sections of the wall and terrain.

Drawing Annotations:

  • EXISTING HEDGE
  • EXISTING LANDSCAPE STEPS
  • ±355
  • EXISTING HOUSE BEYOND
  • ±2400
  • NEW MASONRY WALL C/W 1070 HIGH GUARD RAIL TO BE SELECTED BY OWNERS
  • ±1448
  • EXISTING HEDGE
  • APPROXIMATE HEIGHT OF THE TOP OF EXISTING BOULDER WALL
Page 51
