Attachment 6. A-100 Second Floor Plan

January 23, 2018Page 212 sections

Proposed second-floor layout for the home addition at 53 Knollwood Road.

889 SQ. FT. proposed new area
Architectural drawing titled "SECOND FLOOR PLAN" for a residential property, showing existing structures and proposed new enclosed areas with specific dimensions and square footage calculations.
Architectural drawing titled "SECOND FLOOR PLAN" for a residential property, showing existing structures and proposed new enclosed areas with specific dimensions and square footage calculations.
Page 21

SECOND FLOOR PLAN

Proposed New Enclosed Areas

Area Square Footage
STAIRS 156.5 SQ. FT.
GAMES RM 213 SQ. FT.
MASTER BDRM 313 SQ. FT.
BDRM 206 SQ. FT.
TOTAL PROPOSED NEW 889 SQ. FT.
EXISTING 2ND FLOOR AREA 682 SQ. FT.
TOTAL 2ND FLOOR AREA 1571 SQ. FT.

Project Information

  • Sheet Number: A-100
  • Site: 53 KNOLLWOOD P.L., VIEW ROYAL, BC
  • For: JON & ECHO MICHIEL
  • Drawing Title: FLOOR PLAN
  • Status: CONCEPT DESIGN ONLY
  • Date: 09/20/2017
  • Scale: NTS
  • Designer: TYKO DESIGN LTD, 4122 QUADRA STREET, VICTORIA BC V8X 1K8, TEL 250 818-3265
Page 21
