Attachment 7. A-102 Basement Floor Plan

January 23, 2018Page 221 section

Basement floor plan for 53 Knollwood Road showing existing and proposed storage areas.

1503 SQ. FT. existing basement area

Basement Floor Plan

Architectural basement floor plan showing existing layout including finished areas, laundry, general purpose area, and unfinished rec room, along with a proposed new storage area and stairs leading to the existing garage.
Architectural basement floor plan showing existing layout including finished areas, laundry, general purpose area, and unfinished rec room, along with a proposed new storage area and stairs leading to the existing garage.
Proposed New Enclosed Areas Area
STAIRS - 156.5 SQ. FT.
EXISTING BSMT FLOOR AREA: 1347 SQ. FT.
Total Area Summary Measurement
TOTAL BASEMENT FLOOR AREA: 1503 SQ. FT.
EXISTING GARAGE: 829 SQ. FT.

Project Information

  • Sheet Number: A-102
  • Site: 53 KNOLLWOOD P.L. VIEW ROYAL, BC
  • For: JON & ECHO MICHIEL
  • Drawing Title: FLOOR PLAN
  • Phase: CONCEPT DESIGN ONLY
  • Date: 09/20/2017
  • Scale: NTS
  • Firm: TYKO DESIGN LTD, 4122 QUADRA STREET, VICTORIA BC V8X 1K8, TEL 250 818-3265
