Attachment 9. A-104B Rear Elevation

January 23, 2018Page 241 section

Architectural elevation drawing showing the rear view of the proposed dwelling.

09/20/2017

A-104 B

Rear elevation architectural rendering of a three-story residential building with grey siding, wooden balcony accents, an external staircase, and a detached garage to the left.
Rear elevation architectural rendering of a three-story residential building with grey siding, wooden balcony accents, an external staircase, and a detached garage to the left.
Sheet Number Project Information Drawing Details Date / Scale Designer Information
A-104 B SITE: 53 KNOLLWOOD P.L. VIEW ROYAL, BC
FOR: JON & ECHO MICHIEL		 REAR ELEVATION
CONCEPT DESIGN ONLY		 09/20/2017
NTS		 TYKO DESIGN LTD
4122 QUADRA STREET
VICTORIA BC V8X 1K8
TEL 250 818-3265
