Attachment 11. A-104D Left Elevation

January 23, 2018Page 261 section

Architectural elevation drawing showing the left side view of the proposed dwelling.

09/20/2017

A-104 D: Left Elevation

Architectural concept rendering of the left elevation for a residential project, featuring dark grey exterior walls, two stacked balconies with black railings, and a driveway area leading toward a garage in the background.
Architectural concept rendering of the left elevation for a residential project, featuring dark grey exterior walls, two stacked balconies with black railings, and a driveway area leading toward a garage in the background.
A-104 D SITE:
53 KNOLLWOOD P.L.
VIEW ROYAL, BC		 LEFT ELEVATION 09/20/2017
FOR: JON & ECHO MICHIEL CONCEPT DESIGN ONLY NTS

TYKO DESIGN LTD
4122 QUADRA STREET
VICTORIA BC V8X 1K8
TEL 250 818-3265

Page 26
