Council Meeting/Documents/Attachment 12. Building Height
Appendix

Attachment 12. Building Height

January 23, 2018Page 271 section

Elevation diagram detailing the peak height of the proposed roof structure.

7.5M maximum height11/22/2017

Elevation Height

Project Information Details
Site: 53 Knollwood Rd. View Royal, BC
For: Jon & Echo Michiel
Date: 11/22/2017
Drawing No: A-105 E
Status: Concept Design Only
Scale: NTS
Architectural rendering of the building elevation showing stone, stucco, and wood-cladding finishes with height level indicators
Architectural rendering of the building elevation showing stone, stucco, and wood-cladding finishes with height level indicators

Height and Level Data

Level Elevation
Peak of Roof 8.85
Second Floor 5.43
First Floor 2.77
Average Grade 1.35
Ground Floor 0.00
  • Total Height (Average Grade to Peak of Roof): 7.5m
  • Roof Pitch: 1:12

Contact Information TYKO DESIGN LTD 4122 Quadra Street Victoria BC V8X 1K8 Tel: 250 818-3265

Page 27
