Attachment 7. South Building Elevation - Signage Comparison

May 17, 2016Page 531 section

Comparison elevations showing the building face with and without 'green painted' blank signage areas.

Attachment 7. South Building Elevation

As Proposed

Architectural rendering of the South Building Elevation showing the "As Proposed" design with green painted panels
Architectural rendering of the South Building Elevation showing the "As Proposed" design with green painted panels

1/32" = 1'-0" GREEN PAINTED AREA 30" x 84" 30" x 150" 30" x 150" 30" x 150" 30" x 84"

Without Painted Green Blank Areas

1/32" = 1'-0" GREEN PAINTED AREA 30" x 84" 30" x 150" 30" x 150" 30" x 150" 30" x 84"
