BUILDING HEIGHTS

The document displays nine building elevations labeled Building A1 through Building C3, detailing structural heights and reference levels.

Building Elevation Measurements

• Building A1: Building Height: 7.21 m
• Building A2: Building Height: 7.21 m
• Building A3: Building Height: 7.21 m
• Building B1: Building Height: 7.16 m
• Building B2: Building Height: 7.16 m
• Building B3: Building Height: 7.16 m
• Building C1: Building Height: 7.16 m
• Building C2: Building Height: 7.16 m
• Building C3: Building Height: 7.16 m

Each elevation includes the following structural reference points:

• Midpoint Of Roof
• Top Of Plate
• U.F.E.
• M.F.E.
• Ave. Finished Grade

Project Information

• Project: development permit, 102 ATKINS ROAD, VIEW ROYAL B.C.
• Drawing #: 7548
• Scale: 3/16" = 1'0"
• Drawn by: NS
• Date: 25/1/16
